2023 Odes Junglecross 800ST-2 (Roof & LED Lights)

2023 Odes Junglecross 800ST-2 (Roof & LED Lights)

Aodes

SPECIAL ORDER ONLY PLEASE CALL (320)-358-1994 TO ORDER THANK YOU

(No reviews yet)
Condition:
New
Current Stock:
Description

Item #
Part Number
Description
Specification
Quantity
Warranty Period		 Fits Models
1 10114100000 Roof   1 Not Covered Under Warranty 800-3C/1000-3A/800-3A
2 03414060164 Socket Pan Head Screws M6x16 6 Not Covered Under Warranty 800-3C(19)/800-4C(19)/ATV800/1000-11A（19）/1000-3A(19)/1000-4A(19)/800-3A(19)/800-4A(19)
3 06119061805 Washer ø6×ø18×1 6 Not Covered Under Warranty 800-7/800-3C/800-4C/ATV800/1000-11A/1000-3A/1000-4A/800-3A/800-4A/UTV170
4 10914110060 Rubber Pad ø7Xø20X2 6 Not Covered Under Warranty 800-3C/800-4C/1000-11A/1000-3A/1000-4A/800-3A/800-4A
5 10108800000 Led Light Bar Lower Mounting Plate   1 6 Months (Unlimited Miles) 800-3C/800-4C/1000-11A（19）/1000-3A/1000-4A/800-3A/800-4A
6 01224080166 Hex Flange Bolt M8x16 1 Not Covered Under Warranty 800-3C(19)/800-4C(19)/ATV800(19)/1000-11A（19）/1000-3A(19)/1000-4A(19)/800-3A(19)/800-4A(19)
7 04612080026 Hex Flange Locking Nut 8 M8 1 Not Covered Under Warranty 800-3C(19)/800-4C(19)/ATV800(19)/1000-11A（19）/1000-3A(19)/1000-4A(19)/800-3A(19)/800-4A(19)
8 15109280070 Led Light Bar   1 Not Covered Under Warranty 800-3C(19)/800-4C(19)/1000-11A（19）/1000-3A(19)/1000-4A(19)/800-3A(19)/800-4A(19)
9 10109290040 Led Light Bar Cable Coolant-Proof Mounting Block   1 Not Covered Under Warranty 800-3C/800-4C/1000-3A/1000-4A/800-3A/800-4A
10 15109280080 Led Light Bar Mounting Bracket，Lh   1 Not Covered Under Warranty 800-3C(19)/800-4C(19)/1000-11A（19）/1000-3A(19)/1000-4A(19)/800-3A(19)/800-4A(19)
11 15109280130 Led Light Bar Mounting Bracket，Rh   1 Not Covered Under Warranty 800-3C(19)/800-4C(19)/1000-11A（19）/1000-3A(19)/1000-4A(19)/800-3A(19)/800-4A(19)
12 06119051805 Washer φ5×φ18×1.5 2 Not Covered Under Warranty 800-3C(19)/800-4C(19)/1000-11A（19）/1000-3A(19)/1000-4A(19)/800-3A(19)/800-4A(19)
13 06619051005 Lock Washer ø5 2 Not Covered Under Warranty 800-3C(19)/800-4C(19)/1000-11A（19）/1000-3A(19)/1000-4A(19)/800-3A(19)/800-4A(19)
14 03344050125 Countersunk Allen Screw M5x12 2 Not Covered Under Warranty 800-3C(19)/800-4C(19)/1000-11A（19）/1000-3A(19)/1000-4A(19)/800-3A(19)/800-4A(19)
15 03344080355 Countersunk Allen Screw M8x35 2 Not Covered Under Warranty 800-7/800-3C/800-4C/ATV800/1000-11A/1000-3A/1000-4A/800-3A/800-4A
16 16509280090 Led Light Bar Mounting Rubber   2 Not Covered Under Warranty 800-7/800-3C/800-4C/1000-11A/1000-3A/1000-4A/800-3A/800-4A
17 06119091605 Washer ø8.5×ø16×1.5 2 Not Covered Under Warranty 800-3C/800-4C/ATV800/1000-11A/1000-3A/1000-4A/800-3A/800-4A
18 06619081405 Spring Washer ø8 2 Not Covered Under Warranty 800-3C/800-4C/ATV800/1000-11A（19）/1000-3A/1000-4A/800-3A/800-4A
7 04612080026 Hex Flange Locking Nut M8 2 Not Covered Under Warranty 800-3C(19)/800-4C(19)/ATV800(19)/1000-11A（19）/1000-3A(19)/1000-4A(19)/800-3A(19)/800-4A(19)
19 10109380010 Wire Harness Mounting Clamp ø14 1 Not Covered Under Warranty 800-7/800-3C/800-4C/1000-11A（19）/1000-3A/1000-4A/800-3A/800-4A
2 03414060164 Socket Pan Head Screws M6x16 1 Not Covered Under Warranty 800-3C(19)/800-4C(19)/ATV800/1000-11A（19）/1000-3A(19)/1000-4A(19)/800-3A(19)/800-4A(19)
20 04612060026 Hex Flange Locking Nut M6 1 Not Covered Under Warranty 800-3C(19)/800-4C(19)/ATV800(19)/1000-11A（19）/1000-3A(19)/1000-4A(19)/800-3A(19)/800-4A(19)
21 10114110130 Windshield Storage Box Cap   1 Not Covered Under Warranty #REF!
22 10114100020 Foot Mounting Bushing   4 Not Covered Under Warranty #REF!
23 3144080505 Step Bolt M8×50 2 Not Covered Under Warranty #REF!
24 10114100030 Rubber Washer For Step Bolt   2 Not Covered Under Warranty #REF!
25 10114110120 Torx Nut, Wind Shield   2 Not Covered Under Warranty #REF!
