COOLING SYSTEM

Item #
Part Number
Description
Specification
Quantity		 Fits Models
1 10912050011 Coolant Outlet Pipe, Blue L=1340 1 800-3C/800-4C/1000-11A/1000-3A/1000-4A/800-3A/800-4A
2 10912050030 Coolant Outlet Pipe Clamp   1 800-7/800-3C/800-4C
3 03654050202 Drill Tail Bolt M5×20 3 800-3C/800-4C/1000-11A/1000-3A(19)/1000-4A(19)/800-3A/800-4A(19)/UTV170
4 10912050021 Coolant Inlet Pipe, Blue L=1332 1 800-3C/800-4C/1000-11A/1000-3A/1000-4A/800-3A/800-4A
5 10912050040 Coolant Inlet Pipe Clamp   1 800-3C/800-4C
6 17012070000 Clamp ø20-ø32 4 0
7 10109380030 Wire Harness Mounting Clamp   6 800-7/800-3C/800-4C/1000-11A/1000-3A/1000-4A/800-3A/800-4A/UTV170
8 01254060166 Hex Flange Bolt M6x16 10 800-3C(19)/800-4C(19)/ATV800(19)/1000-11A（19）/1000-3A(19)/1000-4A(19)/800-3A(19)/800-4A(19)
9 04512060027 Rivet Nut M6 4 800-7/800-3C/800-4C/ATV800/1000-11A/1000-3A/1000-4A/800-3A/800-4A/UTV170
10 10912040000 Auxiliary Coolant Tank   1 800-3C/800-4C/1000-11A/1000-3A/1000-4A/800-3A/800-4A
11 04612060026 Hex Flange Locking Nut M6 6 800-3C(19)/800-4C(19)/ATV800(19)/1000-11A（19）/1000-3A(19)/1000-4A(19)/800-3A(19)/800-4A(19)
12 15112050080 Silicone Tube ø6.5x1.5 L=160mm 1 800-7/800-3C/800-4C/1000-11A（19）/1000-3A/1000-4A/800-3A/800-4A
13 11904070040 Hose Clamp φ10 2 800-3C/800-4C/ATV800/1000-11A/1000-3A/1000-4A/800-3A/800-4A
14 15112050080 Silicone Tube ø6.5x1.5 L=160mm 1 800-7/800-3C/800-4C/1000-11A（19）/1000-3A/1000-4A/800-3A/800-4A
15 11904070030 Hose Clamp ￠8 1 800-7/800-3C/800-4C/1000-11A/1000-3A/1000-4A/800-3A/800-4A
16 10112030000 Radiator Upper Support   2 800-3C/800-4C
17 10112020030 Radiator Protection Net   1 800-3C/800-4C
18 10912020000 Radiator Protection Cover   2 800-3C/800-4C
19 01224080206 Hex Flange Bolt M8x20 4 800-3C(19)/800-4C(19)/ATV800(19)/1000-11A（19）/1000-3A(19)/1000-4A(19)/800-3A(19)/800-4A(19)
20 21040400911 Radiator Cap   1
