STEERING SYSTEM(WITH EPS)
| Item # | Part Number |
Description |
Specification |
Quantity |
Fits Models |
| 1 | 10105100000 | Steering Rack Assembly | 1 | 800-7/800-3C/800-4C | |
| 2 | 01214080956 | Hex Flange Bolt | M8x95 | 2 | 800-3C(19)/800-4C(19)/1000-11A（19）/1000-3A(19)/1000-4A(19)/800-3A(19)/800-4A(19) |
| 3 | 01214080806 | Hex Flange Bolt | M8x80 | 1 | 800-3C(19)/800-4C(19)/1000-11A（19）/1000-3A(19)/1000-4A(19)/800-3A(19)/800-4A(19) |
| 4 | 01224080206 | Hex Flange Bolt | M8x20 | 4 | 800-3C(19)/800-4C(19)/ATV800(19)/1000-11A（19）/1000-3A(19)/1000-4A(19)/800-3A(19)/800-4A(19) |
| 5 | 04612080026 | Hex Flange Locking Nut | M8 | 12 | 800-3C(19)/800-4C(19)/ATV800(19)/1000-11A（19）/1000-3A(19)/1000-4A(19)/800-3A(19)/800-4A(19) |
| 6 | 10105100070 | Steering Tie Rod, Lh | 1 | 800-7/800-3C/800-4C | |
| 7 | 10105100090 | Steering Tie Rod, Rh | 1 | 800-3C/800-4C | |
| 8 | 10905100081 | Steering Tie Rod Ball Joint | 2 | 800-7/800-3C/800-4C/1000-11A/1000-3A/1000-4A/800-3A/800-4A | |
| 9 | 06119122505 | Washer | φ12×φ25×1.5 | 2 | 800-7/800-3C/800-4C/1000-11A/1000-3A/1000-4A/800-3A/800-4A |
| 10 | 06619121905 | Lock Washer 12 | φ12 | 2 | 800-7/800-3C/800-4C/1000-11A/1000-3A/1000-4A/800-3A/800-4A/UTV170 |
| 11 | 04725120025 | Castle Nut | M12 | 2 | 800-3C/800-4C/1000-11A（19）/1000-3A/1000-4A/800-3A/800-4A |
| 12 | 05011320255 | Cotter Pin | φ3.2x25 | 2 | 800-7/800-3C/800-4C/1000-11A/1000-3A/1000-4A/800-3A/800-4A |
| 13 | 10105270031 | Steering Shaft | 1 | 800-3C/800-4C | |
| 14 | 10105270020 | Power Steering Universal Joint | 1 | 800-3C/800-4C | |
| 15 | 01224080356 | Hex Flange Bolt | M8x35(full thread) | 3 | 800-3C(19)/800-4C(19)/ATV800(19)/1000-11A（19）/1000-3A(19)/1000-4A(19)/800-3A(19)/800-4A(19) |
| 16 | 10105270011 | Steering Column | 1 | 800-3C/800-4C | |
| 17 | 10709030000 | Ignition Key Switch | 1 | 800-3C/800-4C | |
| 18 | 10910210010 | Combination Switch Bracket | 1 | 800-3C/800-4C | |
| 19 | 03414060164 | Hexagon Socket Pan Head Screws | M6x16 | 2 | 800-3C(19)/800-4C(19)/ATV800/1000-11A（19）/1000-3A(19)/1000-4A(19)/800-3A(19)/800-4A(19) |
| 20 | 01214060356 | Hex Flange Bolt | M6x35 | 1 | 800-3C(19)/800-4C(19)/ATV800(19)/1000-11A（19）/1000-3A(19)/1000-4A(19)/800-3A(19)/800-4A(19) |
| 21 | 10910210020 | Combination Switch Cover | 1 | 800-3C/800-4C | |
| 22 | 10910210030 | Combination Switch Cover Lower Cover | 1 | 800-3C/800-4C | |
| 23 | 10410190000 | Push Pin | M8x15 | 6 | 800-3C(19)/800-4C(19)/1000-11A（19）/1000-3A(19)/1000-4A(19)/800-3A(19)/800-4A(19) |
| 24 | 10905080000 | Steering Wheel | 1 | 800-3C/800-4C | |
| 25 | 10905090000 | Steering Wheel Cover | 1 | 800-3C/800-4C | |
| 26 | 03344060205 | Countersunk Allen Screw | M6x20 | 6 | 800-7/800-3C/800-4C/1000-11A/1000-3A/1000-4A/800-3A/800-4A |
| 27 | 13205270052 | Eps Controller | 1 | 0 | |
| 28 | 01254060126 | Hex Flange Bolt | M6x12 | 2 | 0 |
