Oil Filter
All 2017 SSR SR160TR schematics
2017 SSR SR160TR - Oil Filter Parts Diagram
Click a blue Part # to see its listed verified catalog applications. Click the Description to add or remove the part from your Parts Request.
PART #: Click to view verified catalog applications.
DESCRIPTION: Click to add/remove from your Parts Request.
DESCRIPTION: Click to add/remove from your Parts Request.
| NO. | PART # | DESCRIPTION | MSRP | QTY |
|---|---|---|---|---|
| 1 | A01875-09-00 | OIL FILTER HOUSING+ ADD | $35.00 | 1 |
| 2 | A01876-09-00 | OIL FILTER SPRING+ ADD | $2.50 | 1 |
| 3 | A01816-09-00 | OIL FILTER SCREEN TYPE+ ADD | $28.00 | 1 |
| 4 | A00045-27-00 | O-RING 37X2.5+ ADD | $4.40 | 1 |
| 5 | A01818-09-00 | OIL FILTER COVER+ ADD | $24.50 | 1 |
| 6 | A01879-09-00 | OIL COOLER PIPE INLET+ ADD | $6.10 | 2 |
| 7 | A00004-21-01 | WASHER M8+ ADD | $2.00 | 2 |
| 8 | A00023-19-02 | ALLEN BOLT M4X12+ ADD | $2.50 | 3 |
| 9 | A02498-09-00 | OIL FILTER ASSY+ ADD | $92.80 | 1 |
