Right Crankcase Cover
All 2017 SSR SR250S schematics
2017 SSR SR250S - Right Crankcase Cover Parts Diagram
Click a blue Part # to see its listed verified catalog applications. Click the Description to add or remove the part from your Parts Request.
PART #: Click to view verified catalog applications.
DESCRIPTION: Click to add/remove from your Parts Request.
DESCRIPTION: Click to add/remove from your Parts Request.
| NO. | PART # | DESCRIPTION | MSRP | QTY |
|---|---|---|---|---|
| 1 | A00423-19-08 | CASE FLANGE BOLT M6X30+ ADD | $2.00 | 15 |
| 2 | A00301-09-00 | OIL LEVEL WINDOW+ ADD | $15.80 | 1 |
| 3 | A00306-09-00 | OUTER CLUTCH COVER+ ADD | $62.00 | 1 |
| 4 | A00026-27-00 | O-RING 13.2X2.65+ ADD | $2.00 | 1 |
| 5 | A00304-09-00 | TIMING HOLE PLUG+ ADD | $6.10 | 1 |
| 6 | A00013-26-00 | OIL SEAL 18X30X7+ ADD | $12.30 | 1 |
| 7 | A00025-13-00 | OUTER CLUTCH COVER GASKET+ ADD | $21.00 | 1 |
| 8 | A00302-09-00 | INNER CLUTCH COVER+ ADD | $115.50 | 1 |
| 9 | A00027-13-00 | INNER CLUTCH COVER GASKET+ ADD | $33.30 | 1 |
| 10 | A00010-23-00 | DOWEL PIN 9X13+ ADD | $2.00 | 2 |
| 11 | A00025-27-00 | O-RING 22X3.55+ ADD | $2.60 | 1 |
| 12 | A02566-09-00 | OIL FILLER CAP ASSY W/ O-RING+ ADD | $8.00 | 1 |
| 13 | A00425-19-08 | CASE FLANGE BOLT M6X35+ ADD | $2.00 | 3 |
| 14 | A00419-19-08 | CASE FLANGE BOLT M6X20+ ADD | $2.00 | 1 |
| 15 | A00307-09-00 | WATER PUMP COVER+ ADD | $42.00 | 1 |
| 16 | A00026-13-00 | WATER PUMP COVER GASKET+ ADD | $8.80 | 1 |
| 17 | A00308-09-00 | IMPELLER+ ADD | $17.50 | 1 |
| 18 | A00309-09-00 | WATER PUMP SEAL+ ADD | $35.00 | 1 |
| 19 | A00310-09-00 | WATER PUMP SHAFT+ ADD | $35.00 | 1 |
| 20 | A00007-24-07 | CIRCLIP 22+ ADD | $2.50 | 1 |
| 21 | A00014-26-00 | OIL SEAL 12X24X6+ ADD | $12.30 | 1 |
| 22 | A00015-26-00 | OIL SEAL 14X24X7+ ADD | $12.30 | 1 |
| 23 | A00008-24-07 | CIRCLIP 24+ ADD | $2.00 | 1 |
| 24 | A00038-21-01 | COPPER WASHER 6.5×1.5×12+ ADD | $2.00 | 1 |
