2021 Benelli TNT 135 - Starter, Starter Clutch & Stator/Flywheel Parts Diagram
Click a blue Part # to see its listed TNT135 catalog applications. Click the Description to add or remove the part from your Parts Request.
PART #: Click to view TNT135 catalog applications.
DESCRIPTION: Click to add/remove from your Parts Request.
DESCRIPTION: Click to add/remove from your Parts Request.
| NO. | PART # | DESCRIPTION | MSRP | QTY |
|---|---|---|---|---|
| 1 | 249064320000 | STARTER CLUTCH GEAR+ ADD | $33.00 | 1 |
| 2 | B0205060166H | ALLEN BOLT M6X16+ ADD | $1.50 | 3 |
| 3 | 249104320000 | STARTER CLUTCH ASSY+ ADD | $69.00 | 1 |
| 5 | 290014320010 | FLYWHEEL+ ADD | $77.00 | 1 |
| 6 | B0107060256H | CASE FLANGE BOLT M6X25+ ADD | $1.50 | 2 |
| 7 | B01070501289 | FLANGE BOLT M5x12+ ADD | $1.50 | 2 |
| 8 | 299034320070 | STATOR ASSY+ ADD | $59.00 | 1 |
| 9 | 229072260000 | WASHER+ ADD | $1.50 | 2 |
| 10 | 249114320000 | STARTER IDLER GEAR+ ADD | $13.00 | 1 |
| 11 | 249014320010 | STARTER MOTOR ASSY+ ADD | $96.00 | 1 |
| 12 | B0205060206H | ALLEN BOLT M6X20+ ADD | $1.50 | 2 |
