Product Description
| PLASTIC BODY COMPONENTS | ||||||
 |
||||||
| NO. | PART NUMBER | DESCRIPTION | SPECIFICATION | QTY. | UNIT | PRICE |
| 1 | A00696-02-00 | SEAT | 1 | Pc. | $21.00 | |
| 2 | A00693-02-02 | FRONT FENDER | BLACK | 1 | Pc. | $11.00 |
| 2 | A00693-02-01 | FRONT FENDER | WHITE | 1 | Pc. | $11.00 |
| 2 | A00693-02-04 | FRONT FENDER | GREEN | 1 | Pc. | $11.00 |
| 2 | A00693-02-12 | FRONT FENDER | BLUE | 1 | Pc. | $11.00 |
| 2 | A00693-02-18 | FRONT FENDER | RED | 1 | Pc. | $11.00 |
| 2 | A00693-02-03 | FRONT FENDER | ORANGE | 1 | Pc. | $11.00 |
| 3 | A00694-02-02 | FRONT NUMBER PLATE | BLACK | 1 | Pc. | $8.00 |
| 3 | A00694-02-01 | FRONT NUMBER PLATE | WHITE | 1 | Pc. | $8.00 |
| 3 | A00694-02-04 | FRONT NUMBER PLATE | GREEN | 1 | Pc. | $8.00 |
| 3 | A00694-02-12 | FRONT NUMBER PLATE | BLUE | 1 | Pc. | $8.00 |
| 3 | A00694-02-18 | FRONT NUMBER PLATE | RED | 1 | Pc. | $8.00 |
| 3 | A00694-02-03 | FRONT NUMBER PLATE | ORANGE | 1 | Pc. | $8.00 |
| 4 | A00669-02-02 | RIGHT SHROUD | BLACK | 1 | Pc. | $9.00 |
| 4 | A00669-02-01 | RIGHT SHROUD | WHITE | 1 | Pc. | $9.00 |
| 4 | A00669-02-04 | RIGHT SHROUD | GREEN | 1 | Pc. | $9.00 |
| 4 | A00669-02-12 | RIGHT SHROUD | BLUE | 1 | Pc. | $9.00 |
| 4 | A00669-02-18 | RIGHT SHROUD | RED | 1 | Pc. | $9.00 |
| 4 | A00669-02-03 | RIGHT SHROUD | ORANGE | 1 | Pc. | $9.00 |
| 5 | A00668-02-02 | LEFT SHROUD | BLACK | 1 | Pc. | $9.00 |
| 5 | A00668-02-01 | LEFT SHROUD | WHITE | 1 | Pc. | $9.00 |
| 5 | A00668-02-04 | LEFT SHROUD | GREEN | 1 | Pc. | $9.00 |
| 5 | A00668-02-12 | LEFT SHROUD | BLUE | 1 | Pc. | $9.00 |
| 5 | A00668-02-18 | LEFT SHROUD | RED | 1 | Pc. | $9.00 |
| 5 | A00668-02-03 | LEFT SHROUD | ORANGE | 1 | Pc. | $9.00 |
| 6 | A00670-02-01 | RIGHT SIDE COVER | BLACK | 1 | Pc. | $8.00 |
| 7 | A00671-02-01 | LEFT SIDE COVER | BLACK | 1 | Pc. | $8.00 |
| 8 | A00672-02-02 | REAR FENDER / REAR NUMBER PLATES | BLACK | 1 | Pc. | $16.00 |
| 8 | A00672-02-01 | REAR FENDER / REAR NUMBER PLATES | WHITE | 1 | Pc. | $16.00 |
| 8 | A00672-02-04 | REAR FENDER / REAR NUMBER PLATES | GREEN | 1 | Pc. | $16.00 |
| 8 | A00672-02-12 | REAR FENDER / REAR NUMBER PLATES | BLUE | 1 | Pc. | $16.00 |
| 8 | A00672-02-18 | REAR FENDER / REAR NUMBER PLATES | RED | 1 | Pc. | $16.00 |
| 8 | A00672-02-03 | REAR FENDER / REAR NUMBER PLATES | ORANGE | 1 | Pc. | $16.00 |
| 9 | A00097-20-01 | SCREW | M6X12 | 4 | Pcs. | $1.00 |
| 10 | A00098-20-01 | SCREW | M6X8 | 4 | Pcs. | $1.00 |
| 11 | A00336-22-01 | FLANGE NUT | M6 | 1 | Pc. | $1.00 |
| 12 | A00697-02-00 | FRONT NUMBER PLATE BRACKET | 1 | Pc. | $4.00 | |
| 13 | A00010-19-09 | PAN HEAD ALLEN BOLT | M6X10 | 10 | Pcs. | $1.00 |
| 14 | A00100-20-01 | SCREW | M5X12 | 2 | Pcs. | $1.00 |
| 15 | A00011-21-01 | WASHER | M6 | 1 | Pc. | $1.00 |
| 16 | A00695-02-02 | COMPLETE PLASTIC KIT | BLACK | 1 | Pc. | $32.00 |
| 16 | A00695-02-01 | COMPLETE PLASTIC KIT | WHITE | 1 | Pc. | $32.00 |
| 16 | A00695-02-04 | COMPLETE PLASTIC KIT | GREEN | 1 | Pc. | $32.00 |
| 16 | A00695-02-12 | COMPLETE PLASTIC KIT | BLUE | 1 | Pc. | $32.00 |
| 16 | A00695-02-18 | COMPLETE PLASTIC KIT | RED | 1 | Pc. | $32.00 |
| 16 | A00695-02-03 | COMPLETE PLASTIC KIT | ORANGE | 1 | Pc. | $32.00 |
| 17 | A00095-02-02 | MUFFLER GUARD | BLACK | 1 | Pc. | $9.00 |
