Carburetor And Air Filter
All 2022 SSR SR70AUTO schematics
2022 SSR SR70AUTO - Carburetor And Air Filter Parts Diagram
QTY shows the factory order-entry default, not a verified quantity required for this assembly. Check the part number, VIN restrictions and quantity before requesting.
Some factory table references could not be located on the drawing. Original table references and parts are retained without invented callouts.
Click a blue Part # to see its supported official catalog listings. Click the Description to add or remove the part from your Parts Request.
PART #: Click to view supported official catalog listings.
DESCRIPTION: Click to add/remove from your Parts Request.
DESCRIPTION: Click to add/remove from your Parts Request.
| NO. | PART # | DESCRIPTION | MSRP | QTY |
|---|---|---|---|---|
| 1 | A00328-12-00 | CARBURETOR JK 19 KS W/ O-RING+ ADD | $79.00 | 1 |
| 2 | A00237-14-00 | AIR FILTER ELEMENT 35+ ADD | $19.30 | 1 |
| 2 | A00302-14-00 | AIR FILTER ELEMENT - BUTTON MULTI+ ADD | $26.30 | 1 |
| 3 | A00051-01-00 | CARBURETOR JET KIT AVAILABLE ACCESSORY+ ADD | $38.50 | 1 |
| 4 | A00150-27-00 | O-RING+ ADD | $2.60 | 1 |
| 5 | A00416-12-00 | FLOAT BOWL O-RING JK-PZ19+ ADD | $2.60 | 1 |
| 6 | A00226-14-00 | INTAKE MANIFOLD+ ADD | $31.50 | 1 |
| 7 | A00227-14-00 | INTAKE MANIFOLD GASKET+ ADD | $4.40 | 1 |
| 8 | A00144-27-00 | INSULATOR O-RING+ ADD | $2.60 | 1 |
| 9 | A00126-13-00 | INTAKE INSULATOR+ ADD | $6.10 | 1 |
| 10 | A00422-19-08 | CASE FLANGE BOLT M6X28+ ADD | $2.00 | 2 |
| 11 | A00024-19-01 | FLANGE BOLT M6X22+ ADD | $2.00 | 2 |
