Front Wheel
All 2022 SSR SR70AUTO schematics
2022 SSR SR70AUTO - Front Wheel Parts Diagram
QTY shows the factory order-entry default, not a verified quantity required for this assembly. Check the part number, VIN restrictions and quantity before requesting.
Factory fitment hold: reference 10 / A00391-18-00 is listed as REAR RIM 1.85-14 in this front-wheel assembly alongside 10-inch components. The original row is retained for reference and cannot be selected until SSR confirms the correct part.
Click a blue Part # to see its supported official catalog listings. Click the Description to add or remove the part from your Parts Request.
DESCRIPTION: Click to add/remove from your Parts Request.
| NO. | PART # | DESCRIPTION | MSRP | QTY |
|---|---|---|---|---|
| 1 | A00322-18-00 | FRONT/REAR TIRE 2.50-10+ ADD | $29.80 | 1 |
| 2 | A00323-18-00 | FRONT WHEEL ASSY (BLACK RIM WITH SILVER HUB) 1.4-10 (28 SPOKE)(65X9)+ ADD | $88.20 | 1 |
| 3 | A00324-18-00 | WHEEL SPACER 12X20XH27+ ADD | $6.10 | 1 |
| 4 | A00001-22-03 | FLANGE LOCKNUT M12+ ADD | $2.50 | 1 |
| 5 | A00326-18-00 | FRONT AXLE 12X195XM12X1.25MM+ ADD | $8.80 | 1 |
| 6 | A00219-18-00 | INNER TUBE 2.50-10+ ADD | $15.80 | 1 |
| 7 | A00334-18-00 | RIM STRIP 10"+ ADD | $6.10 | 1 |
| 8 | A00115-28-00 | WHEEL BEARING 6001RS+ ADD | $6.10 | 1 |
| 8A | A00116-28-00 | WHEEL BEARING 6201RS+ ADD | $6.10 | 1 |
| 9 | A00034-26-00 | DUST SEAL 20X32X5+ ADD | $2.60 | 1 |
| 10 | A00391-18-00 | REAR RIM 1.85-14FITMENT REVIEW REQUIRED | $68.30 | 1 |
| 11 | A00512-18-00 | FRONT/REAR SPOKES W/ NIPPLE SET (28PCS/SET) 28 SPOKE (14 INNER/14 OUTER/28 NIPPLES)+ ADD | $24.50 | 1 |
| 12 | A00402-18-00 | FRONT HUB+ ADD | $64.80 | 1 |
Selected Parts (0)
Exact SKU listings from the official SSR fitment chart and individually captured factory catalogs. Check VIN and source restrictions; a listing is not an unrestricted interchangeability guarantee.
