Clutch
2022 SSR TR110 - Clutch Parts Diagram
Click a blue Part # to see its listed verified catalog applications. Click the Description to add or remove the part from your Parts Request.
PART #: Click to view verified catalog applications.
DESCRIPTION: Click to add/remove from your Parts Request.
DESCRIPTION: Click to add/remove from your Parts Request.
| NO. | PART # | DESCRIPTION | MSRP | QTY |
|---|---|---|---|---|
| 1 | A01327-09-00 | CLUTCH WASHER+ ADD | $3.50 | 1 |
| 2 | A01271-09-00 | PRIMARY DRIVE GEAR BUSHING+ ADD | $6.10 | 1 |
| 3 | A01302-09-00 | GEAR 18T+ ADD | $19.30 | 1 |
| 4 | A01301-09-00 | GEAR 67T+ ADD | $24.50 | 1 |
| 5 | A00036-24-07 | CIRCLIP 17+ ADD | $2.00 | 1 |
| 6 | A01213-09-00 | CLUTCH ASSY+ ADD | $91.00 | 1 |
| 7 | A01283-09-00 | TONGUE WASHER M14+ ADD | $2.60 | 1 |
| 8 | A01284-09-00 | DISHED WASHER+ ADD | $2.00 | 1 |
| 9 | A01282-09-00 | SPLINED LOCKNUT M14X1+ ADD | $2.60 | 1 |
| 10 | A00308-13-00 | CLUTCH LIFTER PLATE GASKET+ ADD | $8.80 | 1 |
| 11 | A03025-09-00 | CLUTCH LIFTER PLATE+ ADD | $19.30 | 1 |
| 12 | A00007-20-01 | CS SCREW M5x12+ ADD | $2.00 | 4 |
| 13 | A01280-09-00 | SPRING+ ADD | $2.00 | 1 |
| 14 | A01279-09-00 | COLLAR+ ADD | $2.00 | 1 |
| 16 | A02715-09-00 | CLUTCH ASSY SEMI+ ADD | $117.30 | 1 |
