Fuel Tank
2022 SSR TR110 - Fuel Tank Parts Diagram
Click a blue Part # to see its listed verified catalog applications. Click the Description to add or remove the part from your Parts Request.
PART #: Click to view verified catalog applications.
DESCRIPTION: Click to add/remove from your Parts Request.
DESCRIPTION: Click to add/remove from your Parts Request.
| NO. | PART # | DESCRIPTION | MSRP | QTY |
|---|---|---|---|---|
| 1 | A00335-12-00 | FUEL TANK W/ CAP+ ADD | $64.80 | 1 |
| 2 | A00332-12-00 | FUEL TANK CAP VENT+ ADD | $6.10 | 1 |
| 3 | A00254-12-00 | FUEL FILTER ONLY+ ADD | $4.40 | 1 |
| 3 | A00426-12-00 | FUEL FILTER SR110TR+ ADD | $8.00 | 1 |
| 4 | A00338-12-00 | FUEL PETCOCK+ ADD | $26.30 | 1 |
| 5 | A00011-21-01 | WASHER M6X18X1.5+ ADD | $2.00 | 4 |
| 6 | A00031-19-01 | FLANGE BOLT M6X12+ ADD | $2.00 | 4 |
| 7 | A00002-24-03 | WIRE HOSE CLAMP 7.5+ ADD | $2.00 | 5 |
| 8 | A00001-24-03 | WIRE HOSE CLAMP 10+ ADD | $2.00 | 1 |
| 9 | A00011-19-02 | ALLEN BOLT M6X16+ ADD | $2.00 | 1 |
| 10 | A00093-22-03 | FLANGE NUT M6 (SILVER -OR- BLACK)+ ADD | $2.00 | 1 |
| 11 | A00003-20-01 | SCREW M6X16+ ADD | $2.00 | 1 |
| 12 | A00359-12-00 | FUEL HOSE A=40MM B=100MM C=300MM+ ADD | $6.10 | 1 |
| 13 | A00317-12-00 | FUEL TANK CAP BLACK PLASTIC+ ADD | $15.80 | 1 |
