Product Description
Item # |
Part Number | Description | Specification |
Quantity |
Warranty period |
Fits Models |
1 | 17110150300 | Bed Plate | Yellow | 1 | Not Covered Under Warranty | Jun-00 |
1 | 17110151470 | Dump Bed Bottom Plate | Army | 1 | ||
1 | 17110150290 | Dump Bed Bottom Plate | Black | 1 | ||
2 | 14609070120 | Tail Light | Ltl | 2 | Not Covered Under Warranty | 800-7/1000-7 |
3 | 14610470090 | Hook Ring Seat | Yellow | 4 | Not Covered Under Warranty | 800-7/1000-7 |
3 | 14710470090 | Hook Ring Seat | Black | 4 | Not Covered Under Warranty | 800-7/1000-7 |
4 | 14610470130 | Hook Ring | Yellow | 4 | Not Covered Under Warranty | Jun-00 |
4 | 14710470140 | Hook Ring, Army Green | Green | 4 | ||
4 | 14710470130 | Hook Ring | Black | 4 | ||
5 | 14610470110 | Hook Hinge | Pin | 4 | Not Covered Under Warranty | 800-7/1000-7 |
6 | 05011250255 | Cotter Pin | φ2.5×25 | 4 | Not Covered Under Warranty | 800-3/800-3A/800-4/800-4A/1000-3/1000-3A/1000-4/1000-4A/1000-11/ATV800/800-7/1000-7 |
7 | 14610151110 | Limit Plate, Bed Plate | 2 | Not Covered Under Warranty | 800-7/1000-7 | |
8 | 01214080255 | Hex Flange Bolt | M8×25 | 4 | Not Covered Under Warranty | 800-3/800-3A/800-4/800-4A/1000-3/1000-3A/1000-4/1000-4A/1000-11/ATV800/800-7/1000-7 |
9 | 04612080025 | Hexagon Flange Locking Nut | M8 | 4 | Not Covered Under Warranty | 800-3/800-3A/800-4/800-4A/1000-3/1000-3A/1000-4/1000-4A/1000-11/ATV800/800-7/1000-7 |
10 | 16610151120 | Dump Bed Hinge | Hinge | 2 | ||
11 | 16610151130 | Dump Bed Hinge Bushing | Bushing | 2 | ||
12 | 01256100306 | Hexagon Flange Bolt | M10×30×1.25 | 4 | ||
13 | 17110151520 | Dump Bed Elastic Support Plate (Left) | Left | 1 | ||
14 | 17110151530 | Dump Bed Elastic Support Plate (Right) | Right | 1 | ||
15 | 14610150380 | Heat Insulation, Dump Bed | Box | 1 | Not Covered Under Warranty | 800-7/1000-7 |
16 | 01224060205 | Hex Flange Bolt | M6×20 | 6 | Not Covered Under Warranty | 800-3/800-3A/800-4/800-4A/1000-3/1000-3A/1000-4/1000-4A/1000-11/ATV800/800-7/1000-7 |
17 | 06119061805 | Washer | φ6×φ18×1 | 6 | Not Covered Under Warranty | 800-3/800-3A/800-4/800-4A/1000-3/1000-3A/1000-4/1000-4A/1000-11/ATV800/800-7/1000-7 |
18 | 04512060027 | Rivet Nut | M6 | 14 | Not Covered Under Warranty | 800-3/800-3A/800-4/800-4A/1000-3/1000-3A/1000-4/1000-4A/1000-11/ATV800/800-7/1000-7 |
19 | 10114090120 | Seat Bottom Rubber Rubber, Outside | Outer | 4 | Not Covered Under Warranty | 800-3/800-3A/800-4/800-4A/1000-3/1000-3A/1000-4/1000-4A/800-7/1000-7 |
20 | 01224060205 | Hex Flange Bolt | M6×20 | 8 |
