Product Description
Item # |
Part Number |
Description |
Specification |
Quantity |
Warranty Period |
Fits Models |
| 1 | 15901020090 | Rear Shock Absorber (Blue) | 2 | 12 Months(Unlimited Miles) | 800-3C/800-4C | |
| 2 | 01256120706 | Hex Flange Bolt | M12x70x1.25 | 4 | Not Covered Under Warranty | 800-7/800-3C/800-4C |
| 3 | 04622120026 | Hex Flange Locking Nut | M12x1.25 | 4 | Not Covered Under Warranty | 800-7/800-3C/800-4C/ATV800/1000-11A/1000-3A/1000-4A/800-3A/800-4A |
| 4 | 10701210020 | Sway Bar | 1 | 6 Months (Unlimited Miles) | 800-3C/800-4C | |
| 5 | 10701210040 | Mount, Sway Bar | 2 | Not Covered Under Warranty | 800-3C/800-4C/ATV800 | |
| 6 | 10701210030 | Clamp, Sway Bar | 2 | 6 Months (Unlimited Miles) | 800-3C/800-4C/ATV800 | |
| 7 | 01224080206 | Hex Flange Bolt | M8x20 | 4 | Not Covered Under Warranty | 800-3C(19)/800-4C(19)/ATV800(19)/1000-11A（19）/1000-3A(19)/1000-4A(19)/800-3A(19)/800-4A(19) |
| 8 | 10701210010 | Link Rod, Sway Bar, Lh | 1 | Not Covered Under Warranty | 800-3C/800-4C/ATV800 | |
| 9 | 10701210050 | Link Rod, Sway Bar, Rh | 1 | Not Covered Under Warranty | 800-3C/800-4C/ATV800 | |
| 10 | 04522100026 | Hex Flange Locking Nut | M10x1.25 | 4 | Not Covered Under Warranty | 800-3C/800-4C/ATV800/UTV170 |
| 11 | 13201100050 | Rear Upper A-Arm, Lh | 1 | 12 Months(Unlimited Miles) | 800-3C(19)/800-4C(19) | |
| 12 | 13201110040 | Rear Upper A-Arm, Rh | 1 | 12 Months(Unlimited Miles) | 800-3C(19)/800-4C(19) | |
| 13 | 13201120120 | Rear Lower A-Arm, Lh | 1 | 12 Months(Unlimited Miles) | 800-3C(19)/800-4C(19) | |
| 14 | 13201130120 | Rear Lower A-Arm, Rh | 1 | 12 Months(Unlimited Miles) | 800-3C(19)/800-4C(19) | |
| 15 | 10101070010 | A-Arm Inner Sleeve | 8 | Not Covered Under Warranty | 800-3C/800-4C/1000-11A/1000-3A/1000-4A/800-3A/800-4A | |
| 16 | 10401070020 | A-Arm Nylon Sleeve | 16 | Not Covered Under Warranty | 800-7/800-3C/800-4C/ATV800/1000-11A/1000-3A/1000-4A/800-3A/800-4A | |
| 17 | 10901070090 | Grease Zerk(White) | 8 | Not Covered Under Warranty | 800-7/800-3C/800-4C/ATV800/1000-11A/1000-3A/1000-4A/800-3A/800-4A | |
| 18 | 10101070140 | A-Arm Nylon Sleeve Retainer | 8 | Not Covered Under Warranty | 800-3C/800-4C/1000-11A/1000-3A/1000-4A/800-3A/800-4A | |
| 19 | 01256120756 | Hex Flange Bolt | M12x75x1.25 | 8 | Not Covered Under Warranty | 800-3C/800-4C/1000-11A/1000-3A/1000-4A/800-3A(19)/800-4A |
| 20 | 04622100026 | Hex Flange Locking Nut | M10x1.25 | 12 | Not Covered Under Warranty | 800-7/800-3C/800-4C/ATV800/1000-11A/1000-3A/1000-4A/800-3A/800-4A |
| 21 | 13201200050 | Knuckle Assy, Lh | 1 | 12 Months(Unlimited Miles) | 800-3C/800-4C/ATV800 | |
| 22 | 13201200060 | Knuckle Assy, Rh | 1 | 12 Months(Unlimited Miles) | 800-3C/800-4C/ATV800 | |
| 23 | 13201200080 | Knuckle, Lh | 1 | 12 Months(Unlimited Miles) | 800-3C/800-4C/ATV800 | |
| 24 | 13201200090 | Knuckle, Rh | 1 | 12 Months(Unlimited Miles) | 800-3C/800-4C/ATV800 | |
| 25 | 13201200010 | Knuckle Bushing | 2 | Not Covered Under Warranty | 800-3C/800-4C | |
| 26 | 09560006206 | Bearing(Double Sealed) | 6206 | 4 | Not Covered Under Warranty | 800-3C/800-4C/ATV800/UTV170 |
| 27 | 11010042627 | Oil Seal | 42x62x7 | 2 | Not Covered Under Warranty | 800-3C/800-4C |
| 28 | 11010038628 | Oil Seal | 38x62x8 | 2 | Not Covered Under Warranty | 800-3C/800-4C |
| 29 | 10501200040 | Knuckle Bushing | 4 | Not Covered Under Warranty | 800-3C/800-4C/ATV800 | |
| 30 | 10501200030 | Knuckle Mount Sleeve | 8 | Not Covered Under Warranty | 800-3C/800-4C/ATV800 | |
| 31 | 13201200070 | Grease Zerk(45Degrees) | 2 | Not Covered Under Warranty | 800-3C/800-4C/ATV800/1000-11A/1000-3A/1000-4A/800-3A/800-4A | |
| 32 | 13201200100 | Grease Zerk(90Degrees) | 2 | Not Covered Under Warranty | 800-3C/800-4C/ATV800/1000-11A/1000-3A/1000-4A/800-3A/800-4A | |
| 33 | 10501200020 | Grease Seal For Knuckle | 8 | Not Covered Under Warranty | 800-3C/800-4C/ATV800 | |
| 34 | 01256101106 | Hex Flange Bolt | M10x110x1.25 | 4 | Not Covered Under Warranty | 800-3C/800-4C/UTV170 |
