2023 YCF 50E - Plastics (Engine) Parts Diagram

Click a blue Part # to see where that part is used. Click the Description to add or remove the part from your Parts Request.

FIND & SELECT YOUR PARTS

PART #: Click to view Where Used.
DESCRIPTION: Click to add/remove from your Parts Request.

NO.	PART #	DESCRIPTION	MSRP	QTY
9	YCF-GB70-M5x12	YCF Hexagon Socket Head Bolt, Stainless Steel, M5x12mm | YCF+ ADD	$1.95	1
10	YCF-GB70-M8x16	YCF Hexagon Socket Head Bolt, Stainless Steel, M8x16mm | YCF+ ADD	$3.90	1
14	YCF-YC50-1425-01	YCF Plastic for Motor Front 50E Black+ ADD	$28.65	1
15	YCF-YC50-1426-02	YCF Plastic for Motor Right 50E Black+ ADD	$54.95	1
16	YCF-YC50-1427-02	YCF Plastic for Motor Left 50E Black+ ADD	$37.35	1
17	YCF-YC50-1428-02	YCF Complete Plastic for Motor 50E Black | YCF+ ADD	$73.25	1
18	YCF-RCSC-BK	YCF RCSC-BK MOTEUR88 / 125 Right Crankcase Small Cover (2014 Model)+ ADD	$11.35	2
19	YCF-BT08-M6x10-W	YCF BT08-M6x10-W+ ADD	$2.99	2
22	GB70.2-M6x22	Plus screw M6x22mm for Right crankcase small Cover+ ADD	Call for price	4
23	YCF-BT08-M6x16-W	YCF BT08-M6x16-W+ ADD	$2.99	4
