Frame
2023 YCF 50E - Frame Parts Diagram
Click a blue Part # to see where that part is used. Click the Description to add or remove the part from your Parts Request.
PART #: Click to view Where Used.
DESCRIPTION: Click to add/remove from your Parts Request.
DESCRIPTION: Click to add/remove from your Parts Request.
| NO. | PART # | DESCRIPTION | RETAIL | QTY |
|---|---|---|---|---|
| 1 | YC50-173-03-BK | Frame 50E for KRDIRECTION46, Steering Stem 25° Angle (2022) Black+ ADD | Call for price | 1 |
| 2 | YCF-YC50-2201-04 | YCF Chain Tensioner Component Nylon d40mm x d35mm x 23mm+ ADD | $23.90 | 1 |
| 3 | FB-d22xd8.2x15 | Bushing d22mm x d8.2mm x 15mm+ ADD | Call for price | 1 |
| 4 | YCF-ZT-d12.5xd8.2x16mm | YCF Spacer d12.5 x d8.2 x 16mm+ ADD | $2.95 | 1 |
| 9 | YCF-BT08-M8x50-W | YCF BT08-M8x50-W+ ADD | $2.99 | 1 |
| 11 | YC50-1220 | Rubber Cover (Swingarm Axle)+ ADD | Call for price | 3 |
| 12 | YC50-1221 | Rubber Cover (Bottom of Frame) 50cc+ ADD | Call for price | 2 |
| 13 | YCF-BT08-M8x16-W | YCF BT08-M8x16-W+ ADD | $2.99 | 4 |
| 14 | YCF-YC50-16-05-BK | YCF Stem of Rear Frame Part 50E 2020 Black+ ADD | $108.70 | 1 |
| 15 | YCF-GB91-d2x25-W | YCF GB91-d2x25-W+ ADD | $2.99 | 1 |
| 16 | YCF-YC110-01-08-BK | YCF YC110-01-08-BK+ ADD | $4.99 | 1 |
| 17 | YCF-6900Z | YCF Ball Bearing 6900Z d10 x d22 x 6mm+ ADD | $9.75 | 2 |
| 18 | YCF-YC110-09-01 | YCF YC110-09-01+ ADD | $3.99 | 1 |
| 19 | YCF-YC110-1633-02 | YCF Rubber Plug for Subframe Part D=16mm+ ADD | $9.75 | 1 |
| 21 | YCF-YC50-1621-06-BK | YCF Complete Frame YCF 50E 2026 Black+ ADD | $576.25 | 1 |
| 22 | YCF-GB6187-M10-1.5-W | YCF Hexagon Flat Flange Lock Nut M10-1.5+ ADD | $1.95 | 1 |
| 23 | YCF-YC50-2202 | YCF Tensioner Bracket Assembly 50E+ ADD | $59.50 | 1 |
| 24 | YC50-2022-01 | Tensioner Bracket Assembly (50E)+ ADD | Call for price | 1 |
| 25 | FB22-11x22x2-W | Flat Washer d11 x 22 x 2+ ADD | Call for price | 1 |
