Cylinder Head Covers
All 2026 SSR SR125R schematics
2026 SSR SR125R - Cylinder Head Covers Parts Diagram
Factory source: the combined 2025-2026 SSR SR125R catalog. This page presents the shared factory listing for 2026.
Click a blue Part # to see its listed verified catalog applications. Click the Description to add or remove the part from your Parts Request.
PART #: Click to view verified catalog applications.
DESCRIPTION: Click to add/remove from your Parts Request.
DESCRIPTION: Click to add/remove from your Parts Request.
| NO. | PART # | DESCRIPTION | MSRP | QTY |
|---|---|---|---|---|
| 1 | A01648-09-00 | CYLINDER HEAD COVER+ ADD | $24.50 | 1 |
| 2 | A03294-09-00 | RIGHT CYLINDER HEAD COVER+ ADD | $22.80 | 1 |
| 3 | A03293-09-00 | LEFT CYLINDER HEAD COVER MATTE+ ADD | $21.00 | 1 |
| 4 | A01651-09-00 | TAPPET COVER MATTE W/ FINS+ ADD | $8.80 | 2 |
| 5 | A00162-13-00 | CYLINDER HEAD COVER GASKET+ ADD | $8.80 | 1 |
| 6 | A00325-13-00 | RIGHT CYLINDER HEAD COVER GASKET+ ADD | $8.80 | 1 |
| 7 | A00326-13-00 | LEFT CYLINDER HEAD COVER GASKET+ ADD | $8.80 | 1 |
| 8 | A00328-22-36 | FLANGE CAP NUT M7+ ADD | $2.00 | 4 |
| 9 | A00008-21-01 | WASHER M7+ ADD | $2.00 | 3 |
| 10 | A00269-21-01 | COPPER WASHER M7+ ADD | $2.00 | 1 |
| 11 | A00003-19-05 | FLANGE BOLT M6X16+ ADD | $2.00 | 4 |
| 12 | A00094-27-00 | O-RING+ ADD | $4.40 | 2 |
| 13 | A00135-19-01 | BOLT M6x110+ ADD | $2.00 | 1 |
| 14 | A00421-19-08 | CASE FLANGE BOLT M6X25+ ADD | $2.00 | 2 |
| 15 | C7HSA | SPARK PLUG SUB FOR: TORCH A7TC+ ADD | $8.80 | 1 |
| 16 | A01177-09-00 | ALUMINUM WASHER M6+ ADD | $2.00 | 1 |
