2026 SSR XD150 Clutch
2026 SSR XD150 - Clutch Parts Diagram
Click a blue Part # to see its listed verified catalog applications. Click the Description to add or remove the part from your Parts Request.
PART #: Click to view verified catalog applications.
DESCRIPTION: Click to add/remove from your Parts Request.
DESCRIPTION: Click to add/remove from your Parts Request.
| NO. | PART # | DESCRIPTION | MSRP | QTY |
|---|---|---|---|---|
| 1 | A03218-09-00 | CLUTCH PUSH ROD INNER+ ADD | $2.60 | 1 |
| 2 | A03219-09-00 | CLUTCH PUSH ROD OUTER+ ADD | $2.50 | 1 |
| 3 | A00024-19-01 | FLANGE BOLT M6X22+ ADD | $2.00 | 5 |
| 4 | A00069-28-00 | BEARING 16003/P6+ ADD | $5.30 | 1 |
| 5 | A03220-09-00 | CLUTCH RELEASE PLATE+ ADD | $21.00 | 1 |
| 6 | A03221-09-00 | CLUTCH SPRING+ ADD | $2.50 | 5 |
| 7 | A03222-09-00 | SPLINED NUT+ ADD | $4.40 | 1 |
| 8 | A03223-09-00 | DISHED WASHER+ ADD | $2.50 | 1 |
| 9 | A03224-09-00 | PRESSURE PLATE+ ADD | $45.50 | 1 |
| 10 | A03225-09-00 | FRICTION PLATE+ ADD | $8.00 | 5 |
| 11 | A03226-09-00 | STEEL PLATE+ ADD | $4.40 | 4 |
| 12 | A03227-09-00 | INNER CLUTCH HUB+ ADD | $68.30 | 1 |
| 13 | A03228-09-00 | SPLINED WASHER+ ADD | $2.00 | 1 |
| 14 | A03229-09-00 | CLUTCH BASKET+ ADD | $120.80 | 1 |
| 15 | A03230-09-00 | COMPLETE CLUTCH ASSY+ ADD | $140.00 | 1 |
