BODY
Click parts on table to add
| # | Part # | Description | Price |
|---|---|---|---|
| 1 | A01118-02-01 | Front Number Plate | $15.80 |
| 2 | A01119-02-01 | Front Fender | $19.30 |
| 3 | A01120-02-01 | Left Shroud | $19.30 |
| 4 | A01121-02-01 | Right Shroud | $19.30 |
| 5 | A01122-02-01 | Rear Fender | $21.00 |
| 6 | A00471-12-00 | Fuel Tank | $64.80 |
| 6-1 | A00472-12-00 | Fuel Tank Cap | $15.80 |
| 7 | A00338-12-00 | Fuel Petcock | $26.30 |
| 8 | A00001-19-19 | Allen Bolt M6x8 | $2.00 |
| 9 | A01123-02-00 | Plate Bracket | $10.50 |
| 10 | A00473-12-00 | Tank Damper | $2.60 |
| 11 | A00474-12-00 | Tank Damper | $2.60 |
| 12 | A00002-19-01 | Flange Bolt M6x16 | $2.00 |
| 14 | A00370-14-00 | Airbox | $15.80 |
| 14-1 | A00371-14-00 | Air Filter | $11.50 |
| 14-2 | A00380-14-00 | Airbox Clip | $2.00 |
| 14-3 | A00386-14-00 | Airbox Screen | $5.50 |
| 14-4 | A00387-14-00 | Airbox Collar | $4.50 |
| 15 | A00002-20-03 | ST Screw | $2.00 |
| 16 | A01112-02-02 | Left Fork Guard | $15.80 |
| 17 | A01113-02-02 | Right Fork Guard | $15.80 |
| 18 | A01116-02-02 | Rear Inner Fender | $14.00 |
| 19 | A01117-02-02 | Mudflap | $5.30 |
| 21 | A01111-02-00 | Seat | $75.30 |
| 22 | A00002-21-07 | Rubber Washer | $2.00 |
| 23 | A00002-19-19 | Allen Bolt M6x40 | $2.00 |
| 24 | A01157-02-00 | Collar | $2.00 |
| 25 | A00093-22-03 | Flange Nut M6 | $2.00 |
