CYLINDER HEAD AND CYLINDER
Click parts on table to add
| # | Part # | Description | Price |
|---|---|---|---|
| 1 | A03321-09-00 | Cylinder Head Assy | $103.30 |
| 2 | A00161-13-00 | Head Gasket | $10.50 |
| 3 | A03320-09-00 | Cylinder | $103.00 |
| 4 | A00160-13-00 | Base Gasket | $12.30 |
| 5 | A00003-23-00 | Dowel Pin M8x12 | $2.00 |
| 6 | A00009-27-00 | O-Ring | $2.00 |
| 7 | A00001-23-00 | Dowel Pin M8x14 | $2.00 |
| 8 | A00002-19-03 | Bolt M6x23 | $2.00 |
| 9 | A01769-09-00 | Oil Pipe Bolt | $2.00 |
| 10 | A00019-19-04 | Stud M6x38 | $2.00 |
