Oil Pump
| NO. | PART NUMBER | DESCRIPTION | SPECIFICATION | QTY. | UNIT | RETAIL |
| 1 | A02235-09-00 | OIL STRAINER BODY | 1 | Pc. | $13.00 | |
| 2 | A00072-21-01 | WASHER | 16 | 1 | Pc. | $2.50 |
| 3 | A02236-09-00 | SPLINED NUT | M16 | 1 | Pc. | $4.00 |
| 4 | A00222-13-00 | OIL STRAINER BODY GASKET | 1 | Pc. | $7.00 | |
| 5 | A00036-25-01 | COTTER PIN | 1 | Pc. | $1.50 | |
| 6 | A02237-09-00 | ROTOR CAP | 1 | Pc. | $11.00 | |
| 7 | A02238-09-00 | OIL PASSAGE SPRING | 1 | Pc. | $2.50 | |
| 8 | A00007-20-01 | SCREW | M5X12 | 3 | Pcs. | $1.50 |
| 9 | A02239-09-00 | FILTER BOLT | 1 | Pc. | $2.00 | |
| 10 | A00051-27-00 | O-RING | 9.4X2.4 | 2 | Pcs. | $1.50 |
| 11 | A00009-20-01 | SCREW | M4X12 | 2 | Pcs. | $1.50 |
| 12 | A02240-09-00 | OIL PUMP CAP | 1 | Pc. | $7.00 | |
| 13 | A02241-09-00 | INNER ROTOR | 1 | Pc. | $4.00 | |
| 14 | A02242-09-00 | OUTER ROTOR | 1 | Pc. | $4.00 | |
| 15 | A02243-09-00 | OIL PUMP BRACKET | 1 | Pc. | $14.00 | |
| 16 | A00027-20-01 | SCREW | M6X30 | 2 | Pcs. | $1.50 |
| 17 | A02244-09-00 | DRIVE GEAR | 1 | Pc. | $13.00 | |
| 18 | A02245-09-00 | OIL PUMP SHAFT | 1 | Pc. | $11.00 | |
| 19 | A00201-21-06 | THRUST WASHER | 1 | Pc. | $1.50 | |
| 20 | A02246-09-00 | OIL PUMP BODY | 1 | Pc. | $14.00 | |
| 21 | A00013-19-03 | BOLT | M5X20 | 2 | Pcs. | $1.50 |
| 22 | A02247-09-00 | OIL STRAINER ASSY | 1 | Assy. | $30.00 | |
| 23 | A02248-09-00 | OIL PUMP ASSY | 1 | Assy. | $39.00 |
