Right Crankcase Cover
CLICK PARTS TO ADD
| NO. | PART # | DESCRIPTION | RETAIL | QTY |
|---|---|---|---|---|
| 1 | A00423-19-08 | CASE FLANGE BOLT M6X30 | $2.00 | 15 |
| 2 | A00301-09-00 | OIL LEVEL WINDOW | $15.80 | 1 |
| 3 | A02957-09-00 | OUTER CLUTCH COVER | $68.30 | 1 |
| 4 | A00026-27-00 | O-RING 13.2X2.65 | $2.00 | 1 |
| 5 | A00304-09-00 | TIMING HOLE PLUG | $6.10 | 1 |
| 6 | A00013-26-00 | OIL SEAL 18X30X7 | $12.30 | 1 |
| 7 | A00305-13-00 | OUTER CLUTCH COVER GASKET | $21.00 | 1 |
| 8 | A00302-09-00 | INNER CLUTCH COVER | $115.50 | 1 |
| 9 | A00302-13-00 | INNER CLUTCH COVER GASKET | $28.00 | 1 |
| 10 | A00010-23-00 | DOWEL PIN 9X13 | $2.00 | 2 |
| 11 | A00025-27-00 | O-RING 22X3.55 | $2.60 | 1 |
| 12 | A02566-09-00 | OIL FILLER CAP ASSY W/ O-RING | $8.00 | 1 |
| 13 | A00425-19-08 | CASE FLANGE BOLT M6X35 | $2.00 | 3 |
| 14 | A00419-19-08 | CASE FLANGE BOLT M6X20 | $2.00 | 1 |
| 15 | A02958-09-00 | WATER PUMP COVER | $35.00 | 1 |
| 16 | A00026-13-00 | WATER PUMP COVER GASKET | $8.80 | 1 |
| 17 | A00308-09-00 | IMPELLER | $17.50 | 1 |
| 18 | A00310-09-00 | WATER PUMP SHAFT | $35.00 | 1 |
| 19 | A00175-28-00 | BEARING 6900-P63 | $12.30 | 1 |
| 20 | A00004-24-07 | CIRCLIP 10 | $2.50 | 2 |
| 21 | A02959-09-00 | PIN 3X13.8 | $2.00 | 1 |
| 22 | A00279-21-01 | WASHER 10.2X1X17 | $2.00 | 1 |
| 23 | A00309-09-00 | WATER PUMP SEAL | $35.00 | 1 |
| 24 | A00259-26-00 | MECHANICAL SEAL | $14.00 | 1 |
| 25 | A00007-24-07 | CIRCLIP 22 | $2.50 | 1 |
| 26 | A00015-26-00 | OIL SEAL 14X24X7 | $12.30 | 1 |
| 27 | A00008-24-07 | CIRCLIP 24 | $2.00 | 1 |
| 28 | A00038-21-01 | COPPER WASHER 6.5×1.5×12 | $2.00 | 1 |
| 29 | A02960-09-00 | WATER PUMP COVER JOINT | $12.30 | 1 |
| 30 | A00156-27-00 | O-RING 18X2.0 | $2.60 | 1 |
