| NO. |
PART NUMBER |
DESCRIPTION |
SPECIFICATION |
QTY. |
UNIT |
RETAIL |
| 1 |
A00345-22-01 |
STEERING STEM NUT |
M26 |
1 |
Pc. |
$7.00 |
| 2 |
A00275-21-01 |
WASHER |
26X35X1 |
1 |
Pc. |
$2.50 |
| 3 |
A00249-19-02 |
ALLEN BOLT |
M8X25 |
4 |
Pcs. |
$1.50 |
| 4 |
A00376-15-00 |
UPPER HANDLEBAR HOLDER |
|
2 |
Pcs. |
$18.00 |
| 5 |
A00377-15-00 |
LOWER HANDLEBAR HOLDER |
|
2 |
Pcs. |
$21.00 |
| 6 |
A00378-15-00 |
UPPER TRIPLE CLAMP |
|
1 |
Pc. |
$103.00 |
| 7 |
A00014-19-01 |
FLANGE BOLT |
M8X40 |
8 |
Pcs. |
$2.00 |
| 8 |
A00232-15-00 |
HANDLEBAR VIBRATION DAMPER |
|
4 |
Pcs. |
$1.50 |
| 9 |
A00110-21-01 |
CONVEX WASHER |
26X30X3 |
4 |
Pcs. |
$1.50 |
| 10 |
A00111-21-01 |
WASHER |
12X24X1.5 |
2 |
Pcs. |
$1.50 |
| 11 |
A00001-22-34 |
FLANGE LOCKNUT |
M12 |
2 |
Pcs. |
$2.00 |
| 12 |
A00127-19-04 |
STUD |
M12X72 |
2 |
Pcs. |
$2.50 |
| 13 |
A00379-15-00 |
STEERING STEM |
273MM |
1 |
Pc. |
$59.00 |
| 14 |
A00380-15-00 |
STEERING STOPPER BLOCK |
|
2 |
Pcs. |
$7.00 |
| 15 |
A00003-19-01 |
FLANGE BOLT |
M6X25 |
4 |
Pcs. |
$1.50 |
| 16 |
A00381-15-00 |
LOWER TRIPLE CLAMP W/ STEM |
INCLUDES STEERING STEM |
1 |
Assy. |
$150.00 |
| 17 |
A00445-19-08 |
CASE FLANGE BOLT |
M6X12 |
4 |
Pcs. |
$1.50 |
| 18 |
A01008-02-00 |
LOWER NUMBER PLATE BRACKET |
|
1 |
Pc. |
$13.00 |
| 19 |
A00461-19-01 |
FLANGE BOLT |
M6X8 |
1 |
Pc. |
$1.50 |
| 20 |
A00372-15-00 |
BRAKE HOSE GUIDE BRACKET |
|
1 |
Pc. |
$7.00 |
| 21 |
A00373-15-00 |
BRAKE HOSE GUIDE |
|
1 |
Pc. |
$2.50 |
| 22 |
A00002-19-01 |
FLANGE BOLT |
M6X16 |
1 |
Pc. |
$1.50 |
| 23 |
A00254-26-00 |
DUST SEAL |
|
2 |
Pcs. |
$4.00 |
| 24 |
A00171-28-00 |
STEERING STEM BEARING |
32006 |
2 |
Pcs. |
$27.00 |
| 25 |
A00346-22-01 |
ADJUSTMENT NUT |
M30 |
1 |
Pc. |
$8.00 |
| 26 |
A00732-02-00 |
UPPER FRONT NUMBER PLATE BRACKET |
|
2 |
Pcs. |
$13.00 |
