| NO. |
PART NUMBER |
DESCRIPTION |
SPECIFICATION |
UNIT |
QTY. |
RETAIL |
| 1 |
A00352-05-00 |
FOOTPEG BRACKET ASSEMBLY |
INCLUDES: 1,6,7,8,9,10,11 |
1 |
Pc. |
$63.00 |
| 2 |
A00502-05-00 |
SIDE STAND W/ BOLT + SPRING |
L=190 |
1 |
Assy. |
$27.00 |
| 3 |
A00062-21-01 |
WASHER |
GB93-87 8X13X2 |
4 |
Pcs. |
$1.50 |
| 4 |
A00015-19-01 |
FLANGE BOLT |
GB5789-86 M8X20 S12 |
4 |
Pcs. |
$1.50 |
| 5 |
A00013-21-01 |
WASHER |
GB97.1-85 8X16X1.5 |
4 |
Pcs. |
$1.50 |
| 6 |
A00324-05-00 |
RIGHT FOOTPEG |
|
1 |
Pc. |
$18.00 |
| 7 |
A00326-05-00 |
LEFT FOOTPEG |
|
1 |
Pc. |
$18.00 |
| 8 |
A00336-05-00 |
FOOTPEG PIVOT PIN |
|
2 |
Pcs. |
$1.50 |
| 9 |
A00505-05-00 |
RIGHT FOOTPEG SPRING |
|
1 |
Pc. |
$1.50 |
| 10 |
A00506-05-00 |
LEFT FOOTPEG SPRING |
|
1 |
Pc. |
$1.50 |
| 11 |
A00019-28-01 |
COTTER PIN |
2.5X24 |
2 |
Pcs. |
$1.50 |
| 12 |
A00056-01-00 |
TRAINING WHEEL SET |
AVAILABLE ACCESSORY |
1 |
Kit |
$124.00 |
| 13 |
A00522-18-00 |
TRAINING WHEEL TIRE |
NOT PICTURED |
2 |
Pcs. |
$24.00 |
| 14 |
A00086-01-00 |
TRAINING WHEEL BUSHING |
12MM |
4 |
Pcs. |
$4.00 |
| 14 |
A00102-01-00 |
TRAINING WHEEL BEARING |
16MM |
4 |
Pcs. |
$7.00 |
| 15 |
A00087-01-00 |
TRAINING WHEEL ASSY |
WHEEL W/ TIRE + TUBE (12MM) |
2 |
Pcs. |
$41.00 |
| 15 |
A00087-01-X1 |
TRAINING WHEEL ASSY |
WHEEL W/ TIRE + TUBE (16MM) |
2 |
Pcs. |
$41.00 |
| 16 |
A00523-18-00 |
INNERTUBE 2.50-4 |
NOT PICTURED |
2 |
Pcs. |
$14.00 |
| 17 |
A00089-01-00 |
TRAINING WHEEL KIT REAR BRAKE PEDAL |
NOT PICTURED |
1 |
Pc. |
$18.00 |
