Rear Wheel
Click parts on table to add
| # | Part # | Description | Price | Qty |
|---|---|---|---|---|
| 1 | A00322-18-00 | FRONT/REAR TIRE 2.50-10 | $29.80 | 1 |
| 2 | A00460-18-00 | REAR WHEEL ASSY 1.40-10 (32 SPOKE) | $88.20 | 1 |
| 3 | A00474-04-00 | REAR BRAKE ROTOR 190 16.5XH1.5 | $31.50 | 1 |
| 3A | A00682-04-00 | FRONT/REAR BRAKE ROTOR AFTER VIN ...HC100819 | $31.50 | 1 |
| 4 | A00310-07-00 | REAR SPROCKET 37T | $24.50 | 1 |
| 5 | A00283-18-00 | REAR RIGHT WHEEL SPACER 12X20XH27 | $6.10 | 1 |
| 6 | A00331-18-00 | FRONT WHEEL AXLE 12X215X12X1.25MM | $12.30 | 1 |
| 7 | A00467-18-00 | REAR LEFT WHEEL SPACER 12X20XH33 | $6.10 | 1 |
| 8 | A00007-19-01 | FLANGE BOLT M8X25 | $2.00 | 4 |
| 9 | A00034-19-10 | ROTOR BOLT M8X16 ALLEN | $2.00 | 4 |
| 10 | A00002-22-01 | NUT M8 | $2.00 | 2 |
| 11 | A00286-18-00 | BOLT M8X40 S12 | $2.50 | 2 |
| 12 | A00464-18-00 | CHAIN ADJUSTER PLATE L34 19X36X3X13 | $6.10 | 2 |
| 13 | A00001-22-03 | FLANGE LOCKNUT M12 | $2.50 | 1 |
| 14 | A00219-18-00 | INNER TUBE 2.50-10 | $15.80 | 1 |
| 16 | A00461-18-00 | REAR SPOKES W/ NIPPLE SET (32PCS/SET) | $24.50 | 1 |
| 17 | A00334-18-00 | RIM STRIP 10" | $6.10 | 1 |
| 18 | A00075-28-00 | BEARING 6301-2RS | $6.10 | 2 |
| 19 | A00404-08-00 | REAR WHEEL HUB | $85.80 | 1 |
