| NO. |
PART NUMBER |
DESCRIPTION |
SPECIFICATION |
UNIT |
QTY. |
RETAIL |
| 1 |
A00188-15-00 |
UPPER / LOWER TRIPLE CLAMP ASSY |
|
1 |
Assy. |
$124.00 |
| 2 |
A00168-15-00 |
STEERING STEM BEARING SET |
|
1 |
Set |
$30.00 |
| 3 |
A00231-15-00 |
HANDLEBAR RISER SET |
|
1 |
Set |
$33.00 |
| 4 |
A00237-15-00 |
LOWER TRIPLE CLAMP ASSY |
|
1 |
Assy. |
$77.00 |
| 5 |
A00236-15-00 |
LOWER TRIPLE CLAMP W/ STEM |
|
1 |
Pc. |
$59.00 |
| 6 |
A00234-15-00 |
STEERING STEM NUT |
|
1 |
Pc. |
$4.00 |
| 7 |
A00130-19-03 |
DOMED HEX BOLT |
M8X33 |
4 |
Pcs. |
$2.00 |
| 8 |
A00013-21-01 |
WASHER |
M8 |
6 |
Pcs. |
$1.50 |
| 9 |
A00235-15-00 |
BRAKE HOSE GUIDE |
|
1 |
Pc. |
$2.00 |
| 10 |
A00131-19-03 |
HEX BOLT |
M8X30 |
2 |
Pcs. |
$1.50 |
| 11 |
A00001-21-02 |
LOCK WASHER |
M8 |
6 |
Pcs. |
$1.50 |
| 13 |
A00351-15-00 |
UPPER HANDLEBAR CLAMP |
|
2 |
Pcs. |
$8.00 |
| 14 |
A00392-19-01 |
BOLT |
|
1 |
Pc. |
$4.00 |
| 15 |
A00238-21-01 |
SPECIAL WASHER |
|
1 |
Pc. |
$1.50 |
| 16 |
A00355-15-00 |
UPPER TRIPLE CLAMP |
|
1 |
Pc. |
$48.00 |
| 18 |
A00462-19-03 |
BOLT |
M7X65 |
2 |
Pcs. |
$2.00 |
| 19 |
A00008-22-04 |
LOCKNUT |
M7 |
2 |
Pcs. |
$1.50 |
| 20 |
A00374-15-00 |
RUBBER DAMPER |
|
4 |
Pcs. |
$1.50 |
| 21 |
A00274-21-06 |
CUPPED WASHER |
|
4 |
Pcs. |
$2.00 |
| 22 |
A00401-15-00 |
LOWER HANDLEBAR CLAMP |
|
2 |
Pcs. |
$8.00 |
