Body / Plastics

CLICK PARTS ON TABLE TO ADD
NO. PART NUMBER DESCRIPTION RETAIL QTY
1 A00729-02-02 FRONT FENDER BLACK $19.30 1
1 A00729-02-01 FRONT FENDER WHITE $19.30 1
2 A00730-02-02 FRONT NUMBER PLATE BLACK $15.80 1
2 A00731-02-01 FRONT NUMBER PLATE WHITE $15.80 1
3 A00732-02-02 LEFT SHROUD BLACK $19.30 1
3 A00732-02-01 LEFT SHROUD WHITE $19.30 1
4 A00733-02-02 RIGHT SHROUD BLACK $19.30 1
4 A00733-02-01 RIGHT SHROUD WHITE $19.30 1
5 A00734-02-00 SEAT $75.30 1
6 A00735-02-02 LEFT REAR PLATE BLACK $21.00 1
6 A00735-02-01 LEFT REAR PLATE WHITE $21.00 1
7 A00736-02-02 RIGHT REAR PLATE BLACK $21.00 1
7 A00736-02-01 RIGHT REAR PLATE WHITE $21.00 1
8 A00737-02-02 REAR FENDER BLACK $21.00 1
8 A00737-02-01 REAR FENDER WHITE $21.00 1
9 A00738-02-00 BRAKE HOSE GUIDE $2.00 1
10 A00348-22-04 LOCKNUT M4 $2.00 2
11 A00009-20-01 SCREW M4X12 $2.00 2
12 A00016-21-01 RUBBER WASHER $2.00 6
13 A00093-22-03 FLANGE NUT M6 $2.00 12
14 A00011-21-01 WASHER M6 $2.00 6
15 A00015-19-01 FLANGE BOLT M6X20 $2.00 4
16 A00003-20-01 SCREW M6X16 $2.00 10
17 A00418-19-08 CASE BOLT M6X16 $2.00 4
18 A00739-02-00 FRONT BRACKET $10.50 1
19 A00740-02-00 NUMBER PLATE BRACKET $8.00 1
20 A00001-20-01 SCREW M5X10 $2.00 1
21 A00741-02-00 LOWER FENDER BRACKET $8.00 1
22 A00935-02-02 PLASTIC KIT BLACK $75.30 1
23 A00935-02-01 PLASTIC KIT WHITE $75.30 1
24 A01109-02-00 SPACER $4.40 1
