Crankcase Cover (TX170)
CLICK PARTS ON TABLE TO ADD
| NO. | PART NUMBER | DESCRIPTION | RETAIL | QTY |
|---|---|---|---|---|
| 1 | A01812-09-00 | OUTER CLUTCH COVER | $82.30 | 1 |
| 2 | A00082-27-00 | CLUTCH COVER O-RING | $8.80 | 1 |
| 3 | A02969-09-00 | INNER CLUTCH COVER | $115.50 | 1 |
| 4 | A01815-09-00 | OIL FILTER SPRING | $2.50 | 1 |
| 5 | A01816-09-00 | OIL FILTER SCREEN TYPE | $28.00 | 1 |
| 6 | A00083-27-00 | OIL FILTER COVER O-RING | $2.50 | 1 |
| 7 | A01818-09-00 | OIL FILTER COVER | $24.50 | 1 |
| 8 | A00418-19-08 | CASE FLANGE BOLT M6X16 | $2.00 | 2 |
| 9 | A00435-19-08 | CASE FLANGE BOLT M6X130 | $2.00 | 1 |
| 10 | A00428-19-08 | CASE FLANGE BOLT M6X50 | $2.00 | 1 |
| 11 | A00226-26-00 | OIL SEAL 16X24X5 | $3.50 | 1 |
| 12 | A00102-23-00 | DOWEL PIN | $2.00 | 3 |
| 13 | A01820-09-00 | OIL LEVEL WINDOW | $12.30 | 1 |
| 14 | A00176-13-00 | CLUTCH COVER GASKET | $21.00 | 1 |
| 15 | A00421-19-08 | CASE FLANGE BOLT M6X25 | $2.00 | 3 |
| 16 | A01821-09-00 | CLUTCH CABLE HOLDER | $2.60 | 1 |
| 17 | A00426-19-08 | CASE FLANGE BOLT M6X40 | $2.00 | 4 |
| 19 | A00099-27-00 | O-RING 18x3 | $2.00 | 1 |
| 20 | A01822-09-00 | OIL FILLER CAP | $8.80 | 1 |
| 21 | A01823-09-00 | CLUTCH ACTUATOR | $31.50 | 1 |
| 22 | A00096-27-00 | OIL SEAL 12X18X5 | $2.00 | 1 |
| 23 | A01824-09-00 | CLUTCH ACTUATOR RETURN SPRING | $2.00 | 1 |
| 24 | A00438-19-08 | CASE FLANGE BOLT M6X90 | $2.00 | 1 |
| 25 | A00430-19-08 | CASE FLANGE BOLT M6X65 | $2.50 | 1 |
