Left Crankcase Cover
CLICK PARTS TO ADD
| NO. | PART # | DESCRIPTION | RETAIL | QTY |
|---|---|---|---|---|
| 1 | A03111-09-00 | STATOR W/ FLYWHEEL ASSY | $187.30 | 1 |
| 2 | A03112-09-00 | FLYWHEEL | $106.80 | 1 |
| 3 | A03113-09-00 | STATOR ASSY | $92.80 | 1 |
| 4 | A00003-19-01 | FLANGE BOLT M6X25 | $2.00 | 2 |
| 7 | A00001-19-09 | PAN HEAD BOLT M4X12 | $2.50 | 2 |
| 8 | A00424-19-08 | CASE FLANGE BOLT M6X32 | $2.00 | 2 |
| 9 | A00056-27-00 | O-RING 13.8X2.5 | $2.60 | 1 |
| 10 | A03114-09-00 | INSPECTION PLUG TIMING | $8.80 | 1 |
| 11 | A03115-09-00 | STATOR COVER | $99.80 | 1 |
| 12 | A00057-27-00 | O-RING 63X3 | $2.60 | 1 |
| 13 | A03118-09-00 | STARTER MOTOR CAP | $45.50 | 1 |
| 14 | A00419-19-08 | CASE FLANGE BOLT M6X20 | $2.00 | 2 |
| 15 | A00426-19-08 | CASE FLANGE BOLT M6X40 | $2.00 | 4 |
| 16 | A00055-27-00 | O-RING 27.4X2.4 | $2.00 | 1 |
| 17 | A03116-09-00 | INSPECTION PLUG CRANK | $8.80 | 1 |
| 18 | A00012-19-03 | CASE FLANGE BOLT M6X55 | $2.00 | 1 |
| 19 | A00422-19-08 | CASE FLANGE BOLT M6X28 | $2.00 | 2 |
| 20 | A03117-09-00 | COUNTERSHAFT SPROCKET COVER | $52.50 | 1 |
| 21 | A00314-13-00 | STATOR COVER GASKET | $19.30 | 1 |
