Transmission
CLICK PARTS TO ADD
| NO. | PART # | DESCRIPTION | RETAIL | QTY |
|---|---|---|---|---|
| 1 | A00435-17-00 | TRANSMISSION ASSY | $208.30 | 1 |
| 2 | A00293-21-06 | THRUST WASHER 15X25X1 | $2.50 | 1 |
| 3 | A00436-17-00 | 2ND DRIVING GEAR | $24.50 | 1 |
| 4 | A00437-17-00 | 5TH DRIVING GEAR | $24.50 | 1 |
| 5 | A00294-21-06 | SPLINED WASHER 20X26X1.6 | $2.50 | 3 |
| 6 | A00294-21-01 | WASHER 20 | $2.50 | 3 |
| 7 | A00438-17-00 | 4TH DRIVING GEAR | $24.50 | 1 |
| 8 | A00439-17-00 | 3RD DRIVING GEAR | $24.50 | 1 |
| 9 | A00440-17-00 | MAINSHAFT | $45.50 | 1 |
| 10 | A00295-21-01 | THRUST WASHER 20X27X0.5 | $2.50 | 1 |
| 11 | A00441-17-00 | KICK STARTER GEAR | $21.00 | 1 |
| 12 | A00442-17-00 | MAINSHAFT ASSY | $115.50 | 1 |
| 13 | A00443-17-00 | COUNTERSHAFT ASSY | $106.80 | 1 |
| 14 | A00003-21-06 | THRUST WASHER 15 | $2.50 | 1 |
| 15 | A00444-17-00 | STARTER IDLER GEAR | $21.00 | 1 |
| 16 | A00445-17-00 | STARTER IDLER GEAR BUSHING | $2.50 | 1 |
| 17 | A00296-21-06 | THRUST WASHER 16X24X0.5 | $2.50 | 2 |
| 18 | A00446-17-00 | 1ST DRIVEN GEAR | $24.50 | 1 |
| 19 | A00447-17-00 | 3RD DRIVEN GEAR | $24.50 | 1 |
| 22 | A00448-17-00 | 4TH DRIVEN GEAR | $24.50 | 1 |
| 23 | A00449-17-00 | COUNTERSHAFT | $45.50 | 1 |
| 24 | A00450-17-00 | BUSHING 19.5X16.5X7.5 | $2.50 | 1 |
| 25 | A00451-17-00 | 5TH DRIVEN GEAR | $24.50 | 1 |
| 26 | A00452-17-00 | 2ND DRIVEN GEAR | $24.50 | 1 |
| 27 | A00267-21-01 | WASHER 20X27X1 | $2.50 | 1 |
| 28 | A00020-28-00 | BEARING 6204 | $35.00 | 1 |
| 29 | A00072-28-00 | BEARING NK152312 | $35.00 | 1 |
| 30 | A00067-28-00 | BEARING 6006 | $12.30 | 1 |
| 31 | A00074-28-00 | BEARING NK152312 | $33.30 | 1 |
| 32 | A00453-17-00 | BUSHING 23X20X12 | $2.50 | 2 |
