Engine
Click parts on table to add
| # | Part # | Description | Price | Qty |
|---|---|---|---|---|
| 1 | A00279-05-00 | THROTTLE CABLE 700 120 | $18.00 | 1 |
| 2 | A00202-17-00 | TRANSMISSION BOX | $56.00 | 1 |
| 3 | A00430-19-08 | CASE FLANGE BOLT M6X65 | $2.50 | 2 |
| 4 | A00425-19-08 | CASE FLANGE BOLT M6X35 | $2.00 | 2 |
| 5 | A00209-14-00 | SUPERSEDED TO: A00232-14-00 | $18.00 | 1 |
| 6 | A00210-14-00 | AIR FILTER ADAPTER | $10.00 | 1 |
| 7 | A00253-12-00 | CARBURETOR | $42.00 | 1 |
| 8 | A00171-19-03 | ALLEN BOLT M6X20 - BLACK | $1.50 | 2 |
| 9 | A00211-14-00 | PART DISCONTINUED | $8.00 | 1 |
| 10 | A00295-14-00 | REED CAGE | $18.00 | 1 |
| 11 | A00172-19-03 | BOLT | $1.50 | 2 |
| 12 | A00173-19-03 | BOLT | $1.50 | 2 |
| 13 | A01232-09-00 | CLUTCH ASSY | $33.00 | 1 |
| 14 | A01233-09-00 | CLUTCH LOCK NUT | $1.50 | 1 |
| 15 | A00021-28-01 | WOODRUFF KEY | $2.50 | 1 |
| 16 | BM6A | SPARK PLUG BM6A | $9.00 | 1 |
| 17 | A00407-08-00 | IGNITION COIL | $27.00 | 1 |
| 18 | A00174-19-03 | ALLEN BOLT W/ LOCK WASHER M5X20 | $1.50 | 2 |
| 19 | A00991-09-00 | FLYWHEEL | $8.00 | 1 |
| 20 | A00175-19-03 | BOLT M6x16 | $1.50 | 2 |
| 21 | A00022-28-01 | PIN | $2.50 | 1 |
| 22 | A00992-09-00 | CYLINDER/HEAD | $56.00 | 1 |
| 23 | A00960-09-00 | PULL START ASSY | $33.00 | 1 |
| 24 | A00401-19-X2 | ALLEN BOLT M5X50 | $2.00 | 3 |
| 25 | A00994-09-00 | PISTON | $33.00 | 1 |
| 26 | A00995-09-00 | PISTON RING SET | $18.00 | 1 |
| 27 | A00996-09-00 | CRANKCASE | $42.00 | 1 |
| 28 | A00354-07-00 | COUNTERSHAFT SPROCKET 11T | $14.00 | 1 |
| 29 | A02483-09-00 | CRANKSHAFT ASSY | $45.00 | 1 |
| 30 | A02496-09-00 | ENGINE ASSY | $125.00 | 1 |
| 31 | A00254-12-00 | FUEL FILTER ONLY | $4.40 | 1 |
| 32 | A00255-12-00 | FUEL LINE | $8.00 | 1 |
| 33 | A00338-12-00 | FUEL PETCOCK | $26.30 | 1 |
