| Reference |
Part# |
Description |
Qty |
| 32 |
PIR-GALOW-BK |
Complete Aluminium Handle Bar, "LOW" shape Black L=740mm |
1 |
| 31 |
YC110-0131-03 |
Complete Bar Pad for Chromolly Handlebar L=195mm BLACK |
1 |
| |
YC110-0153-01 |
Handle bar plastic cap |
1 |
| 4 |
PIR-YC110-0138-03 |
YCF complete Throttle Assy. 2020 with BLACK GRIP WITHOUT LOGO |
1 |
| 33 |
PPC09-BK |
set of grip without Logo BLACK |
1 |
| 34 |
YC110-0135-02 |
CNC adjustable bracket with lever 2020 |
1 |
| 35 |
YC110-0151-02 |
Rubber on clutch lever adjustable screw 2020 |
1 |
| 51 |
YC110-0136-01 |
Rubber on clutch lever |
1 |
| |
YC110-0134-04 |
Clutch bracket Assy |
1 |
| 15 |
BT08-M6x20-W |
Hex.Bolt M6x20 mm for clutch lever bracket |
2 |
| 10 |
YC110-0103-07 |
Clutch lever 2020 (with FB13-8x10x10.5-Cu 1EA FB13-8x10x9.4-Cu 1EA ) complete with bushings and washer |
1 |
| 12 |
YC110-0105-15 |
Kill Switch ON/OFF L=580mm |
1 |
| 13 |
YC110-0106 |
Throttle Cable L=840mm A+B=130mm |
1 |
| |
YC110-0143-01 |
RUBBER ON THROTTLE CABLE |
1 |
| 20 |
YC110-01-03-BK |
Cable tie L=150mm BLACK |
3 |
| 20 |
YC110-01-05-WH |
Cable tie L=350mm WHITE |
1 |
| 21 |
YC110-0109-23 |
Clutch Cable Assy. L=920mm A+B=75mm |
1 |
