2026 IBX AX140 140cc Red Manual Pit Bike

2026 IBX AX140 140cc Red Manual Pit Bike

The 2026 IBX AX140 Red combines a YX 140cc four-stroke engine, full manual clutch and performance-focused off-road components in a versatile 17/14-wheel pit bike.

The YX 140cc air-cooled engine with remote oil cooler is paired with a 4-speed manual transmission, giving riders complete control over clutch engagement, shifting and power delivery.

Electric and kick starting, adjustable inverted front suspension, an adjustable rear shock and hydraulic disc brakes make the AX140 a well-equipped choice for riders moving into a more capable manual pit bike.

140cc Four-Stroke Power

The AX140's YX 140cc four-stroke engine provides a step up in displacement from the smaller machines in the IBX AX lineup.

A remote oil cooler assists with engine cooling, while a PZ27 carburetor handles fuel delivery.

Full Manual 4-Speed Transmission

The AX140 features a 4-speed manual transmission with a traditional hand-operated clutch.

Riders control clutch engagement and gear selection themselves, allowing complete control over how engine power is delivered.

Electric & Kick Starting

The AX140 provides the convenience of push-button electric start while retaining a traditional kick starter.

Having both starting systems is a major advantage for riders who want convenient everyday starting with a backup option.

17-Inch Front & 14-Inch Rear Wheels

A 70/100-17 front tire and 90/100-14 rear tire give the AX140 its larger off-road stance.

The 17/14 setup combines increased wheel size with a manageable 33.86-inch seat height.

Adjustable Suspension

The 770mm inverted front fork is adjustable, as is the 280mm rear coil-spring shock.

This gives riders more flexibility in suspension setup than a basic non-adjustable recreational pit bike.

Hydraulic Disc Braking

Front and rear hydraulic disc brakes provide responsive stopping performance.

A 220mm front rotor works with a dual-piston caliper, while the rear uses a 190mm rotor and single-piston caliper.

Classic Red Pit Bike Styling

The Red IBX AX140 combines traditional motocross-inspired red bodywork with black steel rims and aggressive pit-bike styling.

Its 140cc engine, manual transmission, 17/14 wheels and electric start make the AX140 a strong choice for riders looking beyond an entry-level pit bike.

Key Features

• YX 140cc air-cooled four-stroke engine

• Remote oil cooler

• 4-speed manual transmission

• Manual hand clutch

• Electric start

• Kick start

• PZ27 carburetor

• 17-inch front / 14-inch rear wheels

• 33.86-inch seat height

• 13.19-inch ground clearance

• Adjustable 770mm inverted front fork

• Adjustable 280mm rear shock

• Front and rear hydraulic disc brakes

• 220mm front rotor with dual-piston caliper

• 190mm rear rotor

• Double-tube cradle frame

• Heavy-duty steel swingarm

• Black steel rims

• Red color package

2026 IBX AX140 Specifications

Model: PAD140-V2
Engine: YX 140cc Air-Cooled 4-Stroke
Cooling: Air-Cooled with Remote Oil Cooler
Transmission: 4-Speed Manual with Clutch
Starter: Electric & Kick Start
Fuel System: PZ27 Carburetor
Final Drive: Chain
Front Suspension: 770mm Adjustable Inverted Fork
Rear Suspension: 280mm Adjustable Coil-Spring Shock
Front Brake: Hydraulic Disc – 220mm Rotor
Rear Brake: Hydraulic Disc – 190mm Rotor
Front Tire: 70/100-17
Rear Tire: 90/100-14
Seat Height: 33.86 Inches
Ground Clearance: 13.19 Inches
Wheelbase: 50.79 Inches
Fuel Capacity: 6.5 Liters
Battery: 12V 4Ah
Color: Red

140cc Manual Pit Bikes in Minnesota

East Central Sports in Rush City, Minnesota carries IBX off-road pit bikes, dirt bikes, parts and accessories.

For riders looking for a 140cc manual pit bike with electric start, the IBX AX140 offers a YX four-stroke engine, 17/14 wheels, adjustable suspension and hydraulic braking.

Contact East Central Sports for current availability on the 2026 IBX AX140 Red.
