Trailmaster Blazer i200R (Electric)

Trailmaster Blazer i200R (Electric)

Introducing the Trailmaster Blazer i200R — the first mid-size lithium battery go kart in the U.S.! TrailMaster brings advanced electric power to the youth off-road segment with this fully automatic go kart, featuring a 60V 1.8KW motor and 48V 29Ah lithium-ion battery. With instant torque, quiet performance, and zero emissions, the i200R is built for fun and freedom.

The Blazer i200R offers two drive modes for flexibility:

• D Mode: 15 mph for smooth, controlled cruising
• S Mode: 27 mph for spirited riding and trail excitement

A full charge delivers up to 36 miles of range, depending on terrain, weight, and speed.

This electric go kart comes with Trailmaster’s signature safety-first design, requiring the brake pedal to be pressed before throttle engagement. It’s equipped with LED lighting, digital display, rack and pinion steering, and a 5-point safety harness, making it the perfect mid-size electric kart for families who demand performance and reliability.

Specifications

• Battery Type: 48V 29Ah Lithium-ion
• Battery Weight: 14 lbs
• Charging Time: 9 hours
• Range: Up to 36 miles per charge
• Battery Warranty: 2 Years (Limited)
• Motor Power: 1.8KW (1.4KW output)
• Rated Speed: 4350 RPM
• Max Torque: 87Nm / 450A
• Transmission: Fully automatic with reverse (R–N–D–S)
• Drive Modes: “D” up to 15 mph / “S” up to 27 mph
• Climbing Ability: 20 degrees
• Tires (F/R): 16x6-8 / 16x7-8
• Brakes: Rear Hydraulic Disc
• Suspension (F/R): Double A-arm / Double Oil Damped Shock
• Dimensions (LxWxH): 67 x 44 x 51.2 inches
• Wheelbase: 48.4 inches
• Seat Height: 10.2 inches
• Ground Clearance: 2.8 inches
• Pedal to Seat Back Distance: 34–39 inches adjustable
• Net Weight: 352 lbs
• Gross Weight: 435 lbs
• Max Load: 440 lbs

Key Features

• 48V 29Ah Lithium-ion battery with 2-year limited warranty
• Fully automatic with reverse (R–N–D–S modes)
• Two drive speeds: 15 mph (D) and 27 mph (S)
• Strong low-end torque with a 20-degree climbing ability
• Digital LED monitor for speed and battery status
• Safety interlock: brake required before throttle
• Canopy top for shade and protection
• 5-point safety harness seatbelts
• LED headlights and horn
• All-wheel fenders and padded roll cage
• Rack and pinion steering for responsive handling
• Hydraulic disc brake for smooth stopping power
• Individual sport seats for comfort
• Adjustable driver seat (34–39” pedal distance)
• Available in Red or Blue

Maintenance Tips

1. When storing, turn off the main battery switch located above the right rear axle.
2. Charge the battery every two months if not in use.

The Trailmaster Blazer i200R combines proven Trailmaster design with cutting-edge electric technology for a safe, reliable, and eco-friendly ride. Perfect for young and mid-size riders who want the thrill of electric power.

Specifications subject to change without notice. © BV Powersports, LLC
