Engine Valve Timing
ENGINE VALVE TIMING
| Ref# | Part # | Description | Quantity |
| 1 | M150-1001301-N | INTAKE VALVE | 1 |
| 2 | M150-1001307-N | EXHAUST VALVE | 1 |
| 3 | M150-1001310 | STEM SEAL, VALVE | 2 |
| 4 | M150-1001302 | SEAT, VALVE SPRING | 2 |
| 5 | M150-1001303 | INNER SPRING, VALVE | 2 |
| 5 | M150-1001303 | OUTER SPRING, VALVE | 2 |
| 7 | M150-100305 | RETAINER, VALVE SPRING | 2 |
| 8 | M150-1001306 | VALVE COTTER | 4 |
| 9 | M150-1005002 | ROCKER ARM SHAFT SET | 2 |
| 10 | M150-1005200 | INTAKE ROCKER SHAFT | 1 |
| 11 | M150-1005005 | EXHAUST ROCKER SHAFT | 1 |
| 12 | M150-1005100 | CAGING PLATE | 1 |
| 13 | M150-1005300-N | CAMSHAFT COMP | 1 |
| 14 | M150-1005003 | TAPPET SCREW ADJUSTING | 2 |
| 15 | M150-1005004 | TAPPET NUT ADJUSTING | 2 |
