| No. |
U8 Code |
EN name |
Qty/vehicle |
QTY |
Retail |
| 1 |
309001-0139 |
main cable |
1 |
/ea |
$ 68.00 |
| 1 |
309001-0139-04 |
main cable(1.1.24~) |
1 |
/ea |
$ 68.00 |
| 2 |
302001-0007-02 |
voltage regulator |
1 |
/ea |
$ 20.40 |
| 3 |
314001-0003-03 |
electric lock |
1 |
/ea |
$ 20.40 |
| 3 |
314001-0003-04 |
electric lock(1.1.24~) |
1 |
/ea |
$ 20.40 |
| 4 |
312001-0040 |
battery 'MF12V5-1A 12V5AH 113*70*104 |
1 |
/ea |
$ 64.60 |
| 5 |
903018-0005-02 |
flange bolt M6*20 |
1 |
/ea |
$ 3.40 |
| 5 |
903018-0005-03 |
flange bolt M6*20(1.1.24~) |
1 |
/ea |
$ 3.40 |
| 6 |
306001-0017 |
ignition coil |
1 |
/ea |
$ 20.40 |
| 7 |
301001-0001 |
relay |
1 |
/ea |
$ 20.40 |
| 8 |
308002-0012 |
rear light LED Φ63*57*29 |
2 |
/ea |
$ 25.50 |
| 8 |
308002-0012-02 |
rear light LED Φ63*57*29(1.1.24~) |
2 |
/ea |
$ 25.50 |
| 9 |
903018-0003-02 |
flange bolt M6*12 |
2 |
/ea |
$ 3.40 |
| 9 |
903018-0003-03 |
flange bolt M6*12(1.1.24~) |
2 |
/ea |
$ 3.40 |
| 10 |
303001-0007-03 |
CDI |
1 |
/ea |
$ 17.00 |
| 11 |
909010-0011 |
EVA 240*25*2mm |
1 |
/ea |
$ 5.10 |
| 12 |
308001-0027-02 |
front light M4*8 |
2 |
/ea |
$ 42.50 |
| 12 |
308001-0027-03 |
front light M4*8(1.1.24~) |
2 |
/ea |
$ 42.50 |
| 13 |
317002-0002 |
gear indicator L=400 |
1 |
/ea |
$ 20.40 |
| 14 |
315012-0018 |
battery fixing plate 105*24*2 |
1 |
/ea |
$ 17.00 |
| 15 |
316001-0009-02 |
remote controller 59*43*22 |
1 |
/ea |
$ 42.50 |
| 16 |
903020-0029 |
self-tapping nail M4.8*6 |
2 |
/ea |
$ 3.40 |
