Front Lower Suspension

No. U8 Code EN name Qty/vehicle QTY Retail
1 565000-0066-01 right lower rocker arm 257*199*100 orange 1 /ea $ 59.50
1 565000-0066-02 right lower rocker arm 257*199*100 black 1 /ea $ 59.50
2 565000-0065-01 left lower rocker arm 257*199*100 orange 1 /ea $ 59.50
2 565000-0065-02 left lower rocker arm 257*199*100 black 1 /ea $ 59.50
3 903018-0035 flange bolt M10*70*1.25 4 /ea $ 6.80
3 903018-0035-02 flange bolt M10*70*1.25(1.1.24~) 4 /ea $ 6.80
4 908007-0006 sealed cap 'Φ10*35*H8+Φ27.5*6.5 8 /ea $ 5.10
5 902002-0029 plastic bush POM Φ16*27*14+Ф23+H11 8 /ea $ 5.10
6 902001-0026 steel bush 'Φ10.2*16*H46 4 /ea $ 6.80
7 903007-0006 flange locknut M10*1.25 4 /ea $ 5.10
7 903007-0006-02 flange locknut M10*1.25(1.1.24~) 4 /ea $ 5.10
8 603003-0011 ball- joint assy 2 /ea $ 25.50
8-1 603005-0009 nut M10*1.25*H9 2 /ea $ 6.80
9 C90004-0070O right lower rocker arm assy orange 1 /ea $ 76.50
9 C90004-0070B right lower rocker arm assy black 1 /ea $ 76.50
10 C90004-0069O left lower rocker arm assy orange 1 /ea $ 76.50
10 C90004-0069B left lower rocker arm assy black 1 /ea $ 76.50
11 904002-0002-02 cotter pin 2.5*24 2 /ea $ 3.40
11 904002-0002-03 cotter pin 2.5*24(1.1.24~) 2 /ea $ 3.40
