| No. |
U8 Code |
EN name |
Qty/vehicle |
QTY |
Retail |
| 1 |
404000-0161 |
front brake assy |
1 |
/ea |
$ 110.50 |
| 1-1 |
404007-0011 |
front brake pad |
2 |
/ea |
$ 13.60 |
| 1-2 |
404008-0011 |
front brake bracket |
2 |
/ea |
$ 13.60 |
| 1-3 |
404002-0016 |
front brake lever Right Hand Side |
1 |
/ea |
$ 17.00 |
| 1-4 |
404003-0007 |
front brake master cylinder |
1 |
/ea |
$ 28.90 |
| 1-5 |
404005-0020 |
front brake oil pipe |
1 |
/ea |
$ 34.00 |
| 1-6 |
404006-0008 |
front brake caliper |
1 |
/ea |
$ 34.00 |
| 1-7 |
404011-0014 |
front brake switch |
1 |
/ea |
$ 8.50 |
| 2 |
903019-0012-02 |
flange bolt |
4 |
/ea |
$ 3.40 |
| 3 |
903018-0003-02 |
flange bolt |
2 |
/ea |
$ 3.40 |
| 4 |
903018-0011 |
flange bolt |
1 |
/ea |
$ 5.10 |
| 5 |
903007-0004-02 |
lock nut |
1 |
/ea |
$ 3.40 |
| 6 |
405010-0002 |
front brake oil pipe clamp |
2 |
/ea |
$ 6.80 |
| |
404003-0007-30 |
front brake lock tab/bracket |
1 |
/ea |
$ 13.60 |
| |
404011-0010 |
front park lock kit |
1 |
/ea |
$ 13.60 |
