Rear Wheel
| No. | U8 Code | EN name | Qty/vehicle | QTY | Retail |
| 1 | 402005-0039 | rear tire/inner | 1 | /ea | $ 79.90 |
| 1-1 | 402006-0040 | rear tire | 1 | /ea | $ 62.90 |
| 1-2 | 402007-0009 | rear inner tube | 1 | /ea | $ 17.00 |
| 1-3 | 401008-0002 | lining belt | 1 | /ea | $ 5.10 |
| 2 | 402000-0030-02 | rear rim assy. | 1 | /ea | $ 81.60 |
| 2-1 | 402004-0007 | spoke assy. OUTER | 16 | /ea | $ 3.40 |
| 2-2 | 402004-0006 | spoke assy. INNER | 16 | /ea | $ 3.40 |
| 2-3 | 402002-0002 | wheel ring | 1 | /ea | $ 56.10 |
| 3 | 205001-0015 | steel rear sprocket | 1 | /ea | $ 30.60 |
| 4 | 405001-0018 | rear brake disc | 1 | /ea | $ 30.60 |
| 5 | 404011-0001 | front disc bolt | 4 | /ea | $ 5.10 |
| 6 | 901001-0033 | flange axle | 1 | /ea | $ 20.40 |
| 7 | 902001-0071 | flat washer | 1 | /ea | $ 6.80 |
| 8 | 903007-0009 | flange locknut | 1 | /ea | $ 10.20 |
| 9 | 903017-0004 | bolt | 4 | /ea | $ 4.25 |
| 10 | 902001-0066 | flat washer | 1 | /ea | $ 6.80 |
| 11 | 906004-0001 | sprocket lock piece | 2 | /ea | $ 6.80 |
| 907001-0018 | rear hub bearing | 2 | /ea | $ 8.50 |
