BODY PANELS W/ SEAT
| Ref. No. | Name | Part Number | Price Each | Quantity |
|---|---|---|---|---|
| 1 | FRONT FENDER | 801013-0002 | 42.50 | 1 |
| 2 | FRONT RIGHT COVER | 801007-0002-03 | 30.60 | 1 |
| 3 | FRONT LEFT COVER | 801007-0001-03 | 30.60 | 1 |
| 4 | SEAT | 701000-0004-05 | 61.20 | 1 |
| 5 | REAR LEFT COVER | 801007-0003 | 30.60 | 1 |
| 6 | REAR RIGHT COVER | 801007-0004 | 30.60 | 1 |
| 7 | REAR FENDER | 801004-0007-05 | 34.00 | 1 |
| 8 | SCREW | 903012-0007 | 3.40 | 6 |
| 9 | FLANGE NUT | 903006-0002 | 3.40 | 4 |
| 10 | SCREW | 903012-0011 | 3.40 | 3 |
| 11 | RUBBER WASHER | 908003-0002 | 2.55 | 6 |
| 12 | SCREW | 903010-0007 | 3.40 | 1 |
| 14 | OUTER HEXAGON FLANGE BOLT | 903019-0004 | 3.40 | 2 |
| 15 | WASHER | 903002-0002 | 3.40 | 4 |
| 16 | OUTER HEXAGON FLANGE BOLT | 903018-0004 | 3.40 | 3 |
| 17 | NUT | 903008-0024 | 3.40 | 2 |
| 18 | CABLE CLIP | 801003-0011 | 6.80 | 1 |
| 19 | SCREW | 903009-0003 | 3.40 | 2 |
| 20 | FLANGE BOLT | 903019-0004 | 3.40 | 2 |
| 21 | BRACKET | 555000-0181 | 13.60 | 1 |
| 22 | FRONT PLATE | 801013-0001-02 | 30.60 | 1 |
| 23 | NUT | 903007-0001 | 3.40 | 1 |
| 24 | SCREW | 903012-0003 | 3.40 | 1 |
