Crankcase Cover - Left With Stator Assembly
| Ref. No. | Part No. | Description | Price | Qty |
|---|---|---|---|---|
| 1 | 101020-0342 | Left Crankcase Cover Plate | $51.00 | 1 |
| 2 | 101020-0343 | Rear Cover LH | $34.00 | 1 |
| 3 | 101020-0344 | Gasket, Crankcase, LH | $17.00 | 1 |
| 4 | 101020-0345 | Magneto Assy | $85.00 | 1 |
| 5 | 101020-0346 | Rotor, Magneto | $42.50 | 1 |
| 6 | 101020-0347 | Stator, Magneto | $42.50 | 1 |
| 7 | 101020-0348 | Wire Clamp 6 | $8.50 | 1 |
| 8 | 101020-0349 | AC Generator Cap | $8.50 | 1 |
| 9 | 101020-0350 | Hole Plug | $17.00 | 1 |
| 10 | 101020-0351 | Lock Nut | $8.50 | 1 |
| 11 | 101020-0352 | O-Ring 27.4x2.4 | $8.50 | 1 |
| 12 | 101020-0353 | O-Ring 13.8x2.5 | $8.50 | 1 |
| 13 | 101020-0354 | Bolt M6x16 | $6.80 | 1 |
| 14 | 101020-0355 | Set Pin 8x12 | $6.80 | 2 |
| 15 | 101020-0356 | Bolt M6x20 | $6.80 | 2 |
| 16 | 101020-0357 | Bolt M6x28 | $6.80 | 2 |
| 17 | 101020-0358 | Bolt M6x32 | $6.80 | 2 |
| 18 | 101020-0359 | Bolt M6x40 | $6.80 | 3 |
| 19 | 101020-0360 | Screw M5x16 | $6.80 | 2 |
| 20 | 101020-0361 | Wire Clamp 5 | $6.80 | 1 |
| 21 | 101020-0362 | Screw M5x6 | $6.80 | 1 |
| 22 | 101020-0363-02 | Crankcase Cover, LH | $59.50 | 1 |
| 23 | 101020-0364 | O-Ring 10x7.2 | $8.50 | 1 |
| 24 | 101020-0365 | Oil Seal 30x42.4x5 | $17.00 | 1 |
| 25 | 101020-0366 | Bolt M6x105 | $8.50 | 1 |
