FRAME
| Ref. No. | Part No. | Description | Price | Qty |
|---|---|---|---|---|
| 1 | 551000-0105-04 | Frame Assy. | $510.00 | 1 |
| 2 | 552000-0029-02 | Rear Beam Assy. | $115.60 | 1 |
| 3 | 555000-0059 | Battery Box | $25.50 | 1 |
| 4 | 907001-0001 | Bearing | $13.60 | 2 |
| 5 | 902001-0003 | Flat Washer | $5.10 | 1 |
| 6 | 903013-0025 | Screw | $5.10 | 3 |
| 7 | 903019-0024 | Outer Hexagon Head Flange Bolt | $17.00 | 1 |
| 8 | 801004-0008 | Mud Guard | $17.00 | 1 |
| 9 | 903019-0004 | Flange Bolt | $3.40 | 3 |
| 10 | 555000-0125 | Right Lifting Lug | $17.00 | 1 |
| 11 | 555000-0124 | Left Lifting Lug | $17.00 | 1 |
| 12 | 203004-0014 | Chain Roller | $13.60 | 1 |
| 13 | 903007-0006 | Flange Locknut | $5.10 | 1 |
| 14 | 903007-0005 | Flange Locknut | $3.40 | 8 |
| 15 | 903019-0015 | Flange Bolt | $5.10 | 2 |
| 16 | 903013-0024 | Screw | $6.80 | 2 |
| 17 | 903002-0002 | Washer | $3.40 | 3 |
| 18 | 903020-0016 | Screw | $5.10 | 4 |
| 19 | 903019-0012 | Flange Bolt | $3.40 | 2 |
| 20 | 903006-0002 | Flange Nut | $3.40 | 3 |
| 21 | 908004-0008 | Flat Fork Plug | $8.50 | 2 |
| 22 | 903018-0025 | Flange Bolt | $17.00 | 1 |
| 23 | 903018-0022 | Flange Bolt | $17.00 | 1 |
| 24 | 903002-0004 | Flat Gasket | $3.40 | 1 |
