Frame
| No. | U8 Code | EN name | Qty/vehicle | QTY | Retail |
| 1 | 551000-0114-01 | Frame assy | 1 | /ea | $ 476.00 |
| 2 | 555000-0030-03 | CRF/KLX right mounting point | 1 | /ea | $ 17.00 |
| 3 | 555000-0029-03 | CRF/KLX left mounting point | 1 | /ea | $ 17.00 |
| 4 | 903019-0020 | bolt | 2 | /ea | $ 8.50 |
| 5 | 903007-0005 | nut | 4 | /ea | $ 3.40 |
| 6 | 903013-0020 | screw | 2 | /ea | $ 5.10 |
| 7 | 903001-0004 | spring washer | 4 | /ea | $ 3.40 |
| 8 | 903013-0022 | screw | 2 | /ea | $ 5.10 |
| 9 | 203004-0013 | chain roller | 1 | /ea | $ 10.20 |
| 10 | 552000-0033-03 | subframe assy | 1 | /ea | $ 110.50 |
| 11 | 903002-0002 | gasket | 1 | /ea | $ 3.40 |
| 12 | 903018-0003 | flange bolt | 1 | /ea | $ 3.40 |
| 13 | 555000-0009 | Battery case | 1 | /ea | $ 17.00 |
| 14 | 903019-0013 | flange bolt | 2 | /ea | $ 3.40 |
| 15 | 909010-0019 | EVA | 1 | /ea | $ 5.10 |
