The Denago MX3 Blue Edition represents the pinnacle of pit bike engineering, combining competition-grade performance with street-legal versatility in a package designed for riders who demand more. This 140cc powerhouse builds upon Denago's acclaimed MX platform with professional-level components, enhanced durability, and striking blue accents that set it apart from the competition.
140cc Air-Cooled 4-Stroke Engine:
SOHC design producing 13.5 HP at 8,000 RPM
Bore x Stroke: 58mm x 52.4mm (oversquare design for high-RPM power)
External Oil Cooler with high-capacity radiator maintains optimal temps
26mm Mikuni-style Carburetor with altitude-adjustable jetting
High-Performance Red Ignition Coil ensures consistent spark
4-Speed Manual Transmission:
Heavy-Duty Wet Clutch (7 friction plates) handles aggressive riding
Precision-cut gears with positive engagement dogs
Optimized Gear Ratios:
1st: 3.083 (17/52)
2nd: 1.882 (17/32)
3rd: 1.400 (21/30)
4th: 1.130 (23/26)
Inverted Hydraulic Front Forks:
37mm stanchions with 6.3" of travel
20-click compression damping adjustment
Adjustable triple clamps (3 handlebar positions)
Hydraulic Monoshock Rear Suspension:
5.9" of wheel travel
Preload adjustment collar (7 settings)
Rebound damping control
High-Tensile Chromoly Steel Frame:
TIG-welded construction with reinforced gussets
50" wheelbase for high-speed stability
14.5" ground clearance conquers obstacles
Front Hydraulic Disc:
240mm wave rotor
Dual-piston caliper with CNC-machined bracket
Rear Hydraulic Disc:
200mm wave rotor
Single-piston caliper
Folding Levers:
Adjustable reach (6 positions)
7075-T6 aluminum construction
Front Wheel Assembly:
17" diameter | 1.85" width
70/100-17 knobby tire
Rear Wheel Assembly:
14" diameter | 2.50" width
90/100-14 knobby tire
Gold X-Ring Chain:
#428 heavy-duty specification
Self-lubricating design
Stainless Steel Exhaust System:
Ceramic-coated header pipe
USFS-approved spark arrestor
CNC-Machined Components:
Blue-anodized brake reservoirs
Blue-anodized chain adjusters
Blue-anodized fuel vent cap
Keyed Ignition System: Theft deterrent
Side Stand: Convenient parking
Dry Weight: 163 lbs (easy to maneuver)
Fuel Capacity: 1.2 gallons (4.5L)
| Category | Specification |
|---|---|
| Engine | 140cc 4-stroke SOHC |
| Bore x Stroke | 58mm x 52.4mm |
| Compression Ratio | 10.2:1 |
| Fuel System | 26mm Carburetor |
| Transmission | 4-speed manual |
| Final Drive | #428 Gold X-Ring Chain |
| Suspension (F/R) | Inverted Hydraulic / Monoshock |
| Brakes (F/R) | Hydraulic Disc (240mm/200mm) |
| Tires (F/R) | 70/100-17 / 90/100-14 |
| Wheelbase | 50" |
| Seat Height | 35" |
| Ground Clearance | 14.5" |
| Fuel Capacity | 1.2 gal (4.5L) |
| Dry Weight | 163 lbs |
Powerful 4 Stroke Engine
The engine is the lifeline of all powersports products and fun factor of everthing we ride.
Manual 4 Speed Transmission with Activated Clutch
Adjustable Suspension Front & Rear
The comfort and confidence you have in pushing your machine to its fullest potential comes from your suspension, so having a shock tht can adapt to your weight and speed is extremely important.
Adjustable Suspension Front & Rear
Hydraulic Disc Brakes Front & Rear
Having consistent and effective stopping power is as essential as a high-performance engine, nothing stops better then hydraulic disc brakes!
Folding & Adjustable Brake Levers
When a motorcycles falls over, it commonly breaks levers which makes operating the bike very difficult. Our bikes come with retactable brake levers, which reduce that possibility considerably.
Side Stand
Kickstands on motorcycles have been around since the first motorcycle was invented, making parking your bike extremely convenient. Many dirt bikes sold today do not have them, which is a big inconvenience.
Color-Matched Comfort Top Grips
Grips connect the rider to the machine, and our color matched comfort top grips achieve that goal in stride.
Throttle Assembly with Tapered Bearing
Controlling your throttle consistently is the most important thing you will do as a rider, and having a smooth, light throttle is a must in performing this task.
CNC Anodized Aluminum Brake Reservoir Caps
Gold Drive Chain
A motorcycle's chain connects the motor to the rear wheel and produces power to the ground. Denago used a high grade gold-plated chain to ensure that connection.
CNC Andoized Aluminum Chain Adjuster Blocks
Color matched aluminum chain adjuster blacks are one of many high end components on all Denago bikes! They work great and look amazing!
Powder Coated Black Wheels
All Denago bikes come equipped with high quality black anodized rims that work and look great
Powder Coated Black Exhaust System
Color Matched CNC Anodized Aluminum Fuel Vent Cap
High Performance Red Ignition Coil Wire
Keyed Ignition
CNC Andodized Aluminum Folding Shifter Lever
All Denago Bikes come standard with retractable length adjustable aluminum levers!
Stainless Steel Exhaust Pipe
Adjustable Triple Clamps
External Oil Cooler
